Removing

For vehicles with TDI engine

z

Remove noise insulation tray -arrows-.

Fig. 64: Removing Noise Insulation Tray (1.9L TDI)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove left-side noise insulation -arrows-.

z

Part numbers are listed here for reference only. Always check with your
parts department for the latest information.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 65: Removing Left-Side Noise Insulation (1.9L TDI)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with 1.8 ltr. turbo and 2.0 ltr. engines

z

Remove center, left and right insulation trays:

See NOISE INSULATION, ASSEMBLY OVERVIEW .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 66: Removing Center, Left And Right Insulation Trays (1.8L And 2.0L)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with TDI and 1.8 ltr. turbo engines

z

Remove connecting line between charge air cooler and the turbocharger.

Continued for all vehicles

z

Loosen belt pulley hex socket head bolt.

Counter-hold with a hex wrench if necessary.

Fig. 67: Removing Belt Pulley Bolt
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn tightening device in direction of -arrow- to relieve tension on ribbed belt.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 68: Turning Belt Tightening Device In Direction Of Arrow (Vehicles With Power Steering
Pump In Upper Section)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Mark direction of travel of ribbed belt with a crayon or marker before removing the ribbed belt.
Reinstalling a used belt in the opposite direction could damage the belt.

z

Remove ribbed belt.

z

Remove belt pulley hex socket head bolt.

Removing suction line and suction hose

z

Pull connector off suction line.

z

Loosen spring -type clips with special tool VAS 5024.

z

Remove suction line and suction hose

z

Clamp off return supply hose with hose clamps -3094-.

Fig. 69: Clamping Off Return Supply Hose With Hose Clamps -3094-
Courtesy of VOLKSWAGEN OF AMERICA, INC.
