Volkswagen New Beetle. Manual - part 2022





Fig. 13: Pushing Center Cover Forward And Lifting Up To Remove
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Unclip covers -2-. See Fig. 14 .

z

Remove lower switch console cover -1- (remove screws).

Fig. 14: Removing Lower Switch Console Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove screws -arrows-. See Fig. 15 .

z

Remove center air outlet console.

Fig. 15: Removing Center Air Outlet Console
Courtesy of VOLKSWAGEN OF AMERICA, INC.

DEFROSTER AIR OUTLET PANEL, REMOVING

First do the following:



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle



z

Remove radio

See RADIO, REMOVING AND INSTALLING .

z

Remove center air outlet console, See Center air outlet console, removing .

z

Remove plenum panel covers -1- and -2-. See Fig. 16 .

See INSTRUMENT PANEL, REMOVING AND INSTALLING .

z

Remove closeout panels -3- and -4-. See Fig. 16 .

z

Remove spreader rivets -6- and lift out panel -5- from bulkhead clips.

1. Plenum panel cover

z

Driver side

2. Plenum panel cover

z

Passenger side

3. Closeout panel

z

Driver side

4. Closeout panel

z

Passenger side

5. Defroster air outlet panel

6. Spreader rivets

Fig. 16: Removing Defroster Air Outlet Panel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

HEATING AND VENTILATION CONTROLS, REMOVING AND INSTALLING

NOTE:

The following list refers to items in Fig. 16 .



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle



Removing

z

Remove center air outlet console. See Air outlets, removing .

z

Remove mounting screws -arrows-.

Fig. 17: Removing Heating And Ventilation Controls Mounting Screws
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lift out controls with cables from instrument panel in direction of -arrow A-.

z

Detach cables from controls.

z

Disconnect electrical connector.

With controls removed, check function of heating and ventilation cables as follows:

z

Move cables in and out several times -arrow-.

z

Replace damaged or stiff cables.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle



Fig. 18: Checking Function Of Heating And Ventilation Cables
Courtesy of VOLKSWAGEN OF AMERICA, INC.


Installing

z

Attach cable -1- to actuating arm -2- as indicated-arrow-.

Fig. 19: Attaching Cable To Actuating Arm
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press cable for footwell/defrost, cable for temperature flap and cable for central flap -1- into retainer -2-
until it engages.

Fig. 20: Pressing Cable For Footwell/Defrost, Cable For Temperature Flap And Cable For Central

NOTE:

z

Cable sleeves are color coded.

z

All flaps must audibly move onto stops when turning controls.

z

Always check cables before installing. Replace tight or damaged cables.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle
