Flap -1- Into Retainer
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Cable color codes

z

Footwell/defrost flap cable: green

z

Central flap cable: yellow

z

Temperature flap cable: beige

{

Check and adjust cables, See Heating and ventilation cables, installing and adjusting .

{

Connect electrical connector

{

Fit controls into instrument panel opening and install mounting screws.

HEATING AND VENTILATION UNIT, ASSEMBLY

Fig. 21: Identifying Components Of Heating And Ventilation Unit
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Heater core

z

Always use new coolant after replacement

z

Removing:

„

Remove instrument panel.

See INSTRUMENT PANEL, REMOVING AND INSTALLING .

„

Loosen Instrument panel cross member. See Fig. 3 .

„

Carefully pinch off both coolant hoses to heater core and disconnect hoses.

NOTE:

The following list refers to items in Fig. 21 .

CAUTION: The cooling system is pressurized when the engine is warm.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle



z

Partially remove heating and ventilation unit.

z

Press retainer clips and remove heater core.

2. Self-tapping screw

z

Use if retainer clips break

3. Air distribution housing

4. Servo motor for fresh/recirculating air door-V154-

z

Removing and installing, See Servo motor for fresh/recirculating air door -V154-, removing
and installing


5. Self-tapping screw

6. Fresh air blower - V2-

z

Removing see Fig. 2

7. Cover

8. Self-tapping screw

9. Series resistor - N24-

z

Removing, see Fig. 2 .

10. Self-tapping screw

11. Central flap lever

z

Installing and adjusting, See Fig. 22

12. Temperature flap lever

13. Base plate

14. Heater core bulkhead seal

z

Note installation position

z

Installing, See Fig. 23

The central flap pinion has an adjustment mark.

z

Install the lever so that the notches on the lever and the pinion align -arrows-.

Wear gloves and other protection and carefully release system
pressure if necessary, before performing repairs.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle



Fig. 22: Installing Central Flap Lever
Courtesy of VOLKSWAGEN OF AMERICA, INC.

The seal between the heater core and the bulkhead has a positioning mark.

z

Install the seal -1- so that the notches on the seal and the base plate -2- align -3-.

Fig. 23: Identifying Installation Position Heater Core Bulkhead Seal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Servo motor for fresh/recirculating air door -V154-, removing and installing

Removing

z

Remove glove box.

See GLOVE BOX, REMOVING AND INSTALLING .

z

Disconnect electrical connector -1-. See Fig. 24



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle



z

Remove screw -3-.

z

Swing motor -2- downwards.

z

Disconnect motor -2- from fresh air/recirculating air door lever.

Fig. 24: Disconnecting Motor From Fresh Air/Recirculating Air Door Lever
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Replacement motors are supplied with operating levers in the "recirculating air" position. To ease installation,
first do the following:

z

Attach electrical connector -1- to flap motor -2-. See Fig. 25 .

z

Switch on ignition.

z

Operate button for fresh air/recirculating air and observe lever position.

Fig. 25: Attaching Electrical Connector To Flap Motor



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle
