Volkswagen New Beetle. Manual - part 2020





Fig. 1: Identifying Components Location Of Heating And Ventilation System
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Fresh Air Blower

Fig. 2: Exploded View Of Fresh Air Blower Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Heating and ventilation unit

2. Fresh air blower -V2-

3. Cover

4. Screws

NOTE:

The following list refers to items in Fig. 2 .



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle



5. Fresh air blower series resistance with fuse -N24-

Fresh Air Blower Removing

z

Remove glove box.

See GLOVE BOX, REMOVING AND INSTALLING .

z

Remove screws -4- and remove cover -3-. See Fig. 2 .

z

Remove cover containing series resistor -5- and disconnect electrical connector.

z

Disconnect electrical connector from fresh air blower -2-. See Fig. 2 .

z

Remove fresh air blower series resistor -5-. See Fig. 2 .

z

Pull fresh air blower out downwards.

Instrument Panel Cross Member

Fig. 3: Loosening And Tightening Instrument Panel Cross Member
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove securing bolts -arrows-.

z

Tightening torque 25 N.m (18 ft lb)

To access or remove heating and ventilation unit, lift cross member in direction of -arrow A- and
support.

NOTE:

The following list refers to items in Fig. 3 .

NOTE:

z

To prevent damage to the steering column, work should be done with
aid of another technician.

z

If removed component(s) are not to be reinstalled immediately,



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle



Connecting duct, removing

Fig. 4: Connecting Duct Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Bolt

2. Connecting duct

3. Rear duct

4. Retainer

5. Cover

6. Bolt

First do the following:

z

Remove glove box.

See GLOVE BOX, REMOVING AND INSTALLING .

z

Remove steering column trim.

See TRIM UNDER STEERING COLUMN, REMOVING .

z

Remove center air outlet. See Air outlets, removing .

z

Remove center console.

secure the cross member to the bulkhead.

z

Any wiring harnesses released from their retainers must be secured
again at the same point, using the same method of securing.

NOTE:

The following list refers to items in Fig. 4 .



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle



See STORAGE, COVERS AND TRIMS .

Removing Connecting duct

z

Remove retainer -4-.

z

Remove cover -5-.

z

Pull connecting piece out towards the driver's side footwell -arrow A-.

Fig. 5: Pulling Connecting Piece Out Towards Driver's Side Footwell
Courtesy of VOLKSWAGEN OF AMERICA, INC.

DUST AND POLLEN FILTER, REMOVING AND INSTALLING

The filter is located in the right rear of the instrument panel under a cover.

Fig. 6: Identifying Components Of Dust And Pollen Filter

NOTE:

The following list refers to items in Fig. 5 .



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Heating, Ventilation - New Beetle
