Volkswagen New Beetle. Manual - part 2012





Fig. 37: Identifying A/C Components In Engine Compartment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Damper*

2. Refrigerant hose*

z

With damper

3. Refrigerant pipe*

4. Ambient temperature switch -F38-

z

Switches off A/C clutch -N25- at low ambient temperatures

z

Off at -1°C (30°F)

z

On at 7°C (45° F)

5. Refrigerant pipe

NOTE:

The following list refers to items in Fig. 37 .



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



z

From receiver drier to expansion valve

6. Low pressure service valve

z

Only use Kent Moore ACR4 or equivalent

7. A/C pressure switch -F129- or high pressure sensor -G65-

z

Depending on engine type, refrigerant systems have either an A/C pressure switch -F129- or high
pressure sensor -G65- instralled. Refer to system wiring diagrams.

z

Checking -F129-, See A/C pressure switch -F129-, checking .

z

Checking -G65-, See High pressure sensor -G65-

z

Removing and installing, See Removing And Installing A/C Pressure Switch -F129- And High
Pressure Sensor -G65-
 .

z

Component can be removed without discharging refrigerant system

8. Expansion valve*

9. Evaporator water drain valve (Models From 06.00 And Up)

z

New valve design, models from 06.00 and up, See CHECKING EVAPORATOR WATER
DRAIN VALVE - Models From 06.00 And Up
 .

10. Evaporator water drain valve (models Up To 06.00)

z

Checking models Up To 06.00, See CHECKING EVAPORATOR WATER DRAIN VALVE -
Models Up To 06.00


11. A/C cut-out thermal switch -F163-

z

Switches off A/C clutch -N25- at excessively high coolant temperature

z

Off at 119°C (246°F)

z

On at 112°C (234°F)

12. Coolant fan control (FC) control module -293-

13. Refrigerant hose*

z

From compressor to condenser

14. Refrigerant hose

z

From expansion valve to compressor

z

With damper

15. Pressure relief valve*

z

On compressor

z

Checking see Pressure relief valve .

16. Condenser*

17. Compressor*

z

Sanden SD7-V16

18. A/C clutch -N25-

z

Servicing, See A/C clutch -N25-, servicing (Sanden) .

19. Receiver drier*



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



Checking Evaporator Water Drain Valve - Models Up To 06.00

Fig. 38: Evaporator Water Drain Valve - Models Up To 06.00
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



z

Fold cover -1- in bulkhead insulation mat -3- upwards.

z

Remove drain valve -2- from opening in bulkhead -4-.

Check water drain valve as follows to ensure correct function:

z

The water drain valve must not be stuck together.

z

Insulation mat must not be deformed or damaged in the area of water drain valve.

z

The opening in the sealing cap of the water drain valve must point downwards.

Checking Evaporator Water Drain Valve - Models From 06.00 And Up

NOTE:

When the cover cap -1- is closed it must be flush with the insulation matting. If
the cover cap -1- is pushed in too far, the water drain valve sealing cap -2- can
become jammed.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle
