Volkswagen New Beetle. Manual - part 2010





Fig. 32: Identifying Components Of Heating And A/C Controls Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



1. Heating and A/C controls

z

With A/C switch -E35-

z

With fresh air blower switch -E9-

z

With switch for fresh air blower and recirculated air -E184-

z

Removing and installing, See Heating and A/C controls, removing and installing .

2. Illumination filter

3. Trim panel

4. Fresh air control lever light -L16-

z

12V, 1.2W

5. Rotary control

z

For blower speed

z

To remove: Use pliers with suitable plastic or rubber protection on jaws

6. Rotary control

z

For air distribution

z

To remove: Use pliers with suitable plastic or rubber protection on jaws

7. Rotary control

z

For interior temperature

z

To remove: Use pliers with suitable plastic or rubber protection on jaws

HEATING AND A/C CABLES, INSTALLING AND ADJUSTING

NOTE:

The following list refers to items in Fig. 32 .

NOTE:

z

Cable sleeve ends are color coded.

z

Check cables before installing. Replace binding or damaged cables.

z

Attach cables to removed controls first and then attach to levers at
heating/evaporator unit.

z

All air flaps must audibly move onto end stops when turning controls.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



Fig. 33: Installing Heating And A/C Cables
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Central flap cable

z

From air distribution rotary control to central flap

z

Cable sleeve marking: Yellow

z

Installing and adjusting, See Central flap cable, installing and adjusting .

NOTE:

The following list refers to items in Fig. 33 .



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



2. Footwell/defrost flap cable

z

From air distribution rotary control to footwell/defrost flap

z

Cable sleeve marking: Green

z

Removing:

„

Remove heating and A/C controls, See Heating and A/C controls, removing and installing

„

Unclip cable from controls

„

Remove steering column trim.

See TRIM UNDER STEERING COLUMN, REMOVING .

„

Unclip cable at heater/evaporator unit.

z

Installing and adjusting, See Footwell/defrost flap cable, installing and adjusting .

3. Heating and A/C controls

z

Removing and installing, See Heating and A/C controls, removing and installing .

4. Temperature flap cable

z

From temperature rotary control to temperature flap

z

Cable sleeve marking: Beige

z

Installing and adjusting, See Temperature flap cable, installing and adjusting .

Temperature flap cable, installing and adjusting

Cable sleeve marking: Beige

Prerequisites:

z

Heating and A/C controls are installed.

z

Connecting duct removed, See CONNECTING DUCT, REMOVING



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle
