2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



Fig. 29: Moving Heating And A/C Cables In And Out Several Times
Courtesy of VOLKSWAGEN OF AMERICA, INC.


Installing

z

Attach cable -1- to actuating arm -2- as indicated-arrow-.

Fig. 30: Attaching Cable To Actuating Arm
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press cable for footwell/defrost, cable for temperature flap and cable for central flap -1- into retainer -2-
until it engages.

NOTE:

z

Cable sleeves are color coded.

z

All flaps must audibly move onto stops when turning controls.

z

Always check cables before installing. Replace tight or damaged cables.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



Fig. 31: Pressing Cable For Footwell/Defrost, Cable For Temperature Flap And Cable For Central
Flap Into Retainer

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Cable color codes

z

Footwell/defrost flap cable: green

z

Central flap cable: yellow

z

Temperature flap cable: beige

{

Check and adjust cables, See Heating and A/C cables, installing and adjusting .

{

Connect electrical connector

{

Fit controls into instrument panel opening and install mounting screws.

HEATING AND A/C CONTROLS, ASSEMBLY



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle
