Volkswagen New Beetle. Manual - part 2008





z

Removing and installing, See Heating and A/C controls, removing and installing .

z

Assembly, See Heating and A/C controls, assembly .

2. Dust and pollen filter

z

Removing and installing, See DUST AND POLLEN FILTER, REMOVING AND
INSTALLING
 .

3. Side window air outlet

z

Removing, See SIDE WINDOW AIR OUTLETS, REMOVING .

4. Side air outlets

z

Removing, See SIDE WINDOW AIR OUTLETS, REMOVING

5. Center air outlet console

z

Removing, See CENTER AIR OUTLET CONSOLE, REMOVING

6. Instrument panel cross member

z

Loosening and tightening, See INSTRUMENT PANEL CROSS MEMBER

7. Servo motor for fresh/recirculating air door -V154-

z

Removing and installing, See SERVO MOTOR FOR FRESH/RECIRCULATING AIR DOOR
-V154-, REMOVING AND INSTALLING


8. Fresh air blower -V2-

z

Removing, See FRESH AIR BLOWER REMOVING

9. Fresh air blower series resistance with fuse -N24-

z

Removing, See FRESH AIR BLOWER REMOVING

10. Intermediate duct

11. Cables

z

Installing and adjusting, See HEATING AND VENTILATION CABLES, INSTALLING AND
ADJUSTING


12. Rear footwell duct

13. Gasket

14. Connecting duct

z

With front footwell air outlet

z

Removing, See CONNECTING DUCT, REMOVING

15. Heater/evaporator unit*

z

Disassembly and assembly, See Heater/evaporator unit, disassembly and assembly

16. Heater core*

z

Removing, See Heater/evaporator unit, disassembly and assembly

z

Always use new coolant after replacement

17. Heater core/bulkhead seal

z

Note installation position, See HEATING AND VENTILATION UNIT, ASSEMBLY

18. Defroster duct

z

Replacing:



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



„

Remove instrument panel

See INSTRUMENT PANEL, REMOVING AND INSTALLING

„

Loosen instrument panel cross member, See INSTRUMENT PANEL CROSS MEMBER

19. Instrument panel

z

Removing and installing

See INSTRUMENT PANEL, REMOVING AND INSTALLING

20. Center air outlet duct

21. Defroster air outlet panel

z

Removing, See SIDE WINDOW AIR OUTLETS, REMOVING

HEATING AND A/C CONTROLS, REMOVING AND INSTALLING

Removing

z

Remove center air outlet console, See CENTER AIR OUTLET CONSOLE, REMOVING

z

Remove mounting screws -arrows-.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



Fig. 28: Removing Heating And A/C Controls Mounting Screws
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lift out controls with cables from instrument panel in direction of -arrow A-.

z

Detach cables from controls.

z

Disconnect electrical connector.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



With controls removed, check function of heating and ventilation cables as follows:

z

Move cables in and out several times -arrow-.

z

Replace damaged or stiff cables.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle
