Volkswagen New Beetle. Manual - part 1974





Selectable diagnostic modes under address word 33 - OBD

SELECTABLE DIAGNOSTIC MODES UNDER ADDRESS WORD 33 - OBD

Terminals at Engine Control Module
(ECM)

80

121

121

121

Emissions limiting values according
to

LEV

(1)

ULEV

(2)

LEV

(1)

ULEV

(2)

On Board Diagnostic (OBD)

OBD II

OBD II

OBD II

OBD II

DTC memory

(3)

Permanent

Permanent

Permanent

Permanent

Memory for adaptation values

(4)

Temporary

Temporary

Temporary

Temporary

Oxygen sensor control

2 sensors

2 sensors

2 sensors

2 sensors

Knock sensor control

2 knock sensors

2 knock

sensors

2 knock

sensors

2 knock

sensors

Intake manifold change-over

No

No

No

Yes

Camshaft adjustment

No

No

No

No

Boost pressure regulation

No

No

No

No

Secondary Air Injection (AIR) system

Yes

Yes

Yes

Yes

Electronic engine load regulation
system

No

Yes

Yes

Yes







(1) 1)

 LEV = Low Emission Vehicles (emission values max. 0.075 g/mi HC).

(2) 2)

 ULEV = Ultra Low Emission Vehicles (emission values max. 0.040 g/mi HC).

(3) 3)

 Independent of voltage supply.

(4) 4)

 Values are erased when voltage supply is interrupted.

NOTE:

The conditions required for selecting the desired diagnostic mode are listed in
the following table:

Diagnostic mode

Requirement:

Selectable diagnostic modes under address word 33 -
OBD

z

engine

off

z

Ignition

switched

on.

z

Engine

running

at idle

z

Vehicle

in drive

mode

Mode
1:

Check measured

values

See DIAGNOSTIC MODE

1: CHECK MEASURED

VALUES

Yes

Yes

Yes

Mode
2:

Checking

operating

See DIAGNOSTIC MODE

2: CHECKING

Yes

Yes

Yes



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 2.0L Generic Scan Tool - New Beetle



Connect diagnostic tester

Recommended special tools and equipment

z

VAS 5052 Vehicle Diagnostic and Information System with

conditions

OPERATING

CONDITIONS

Mode
3:

Check DTC

Memory

See DIAGNOSTIC MODE

3: CHECK DTC MEMORY

Yes

(1)

Yes

Yes

Mode
4:

Reset/erase

diagnostic data

See DIAGNOSTIC MODE

4: RESET/ERASE

DIAGNOSTIC DATA

Yes

Yes

Yes

Mode
5:

Check output of

oxygen sensor

signals

See DIAGNOSTIC MODE

5: CHECK OUTPUT OF

OXYGEN SENSOR

SIGNALS

Yes

Yes

Yes

Mode
6:

Check test results

of components

that are not

continuously

monitored

See DIAGNOSTIC MODE

6: CHECK TEST

RESULTS OF

COMPONENTS THAT

ARE NOT

CONTINUOUSLY

MONITORED

No

Yes

Yes

Mode
7:

Check test results

of components

that are

continuously

monitored

See DIAGNOSTIC MODE

7: CHECK TEST

RESULTS OF

COMPONENTS THAT

ARE CONTINUOUSLY

MONITORED

Yes

(1)

Yes

Yes

Mode
8:

Tank leak test

See DIAGNOSTIC MODE

8: TANK LEAK TEST

No

Yes

No

Mode
9:

Vehicle

information

See DIAGNOSTIC MODE

9: VEHICLE

INFORMATION

Yes

Yes

Yes

(1)

Perform only with ignition switched on when engine does not start (operate starter beforehand for at
least 6 seconds).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 2.0L Generic Scan Tool - New Beetle



Fig. 1: Identifying VAS 5052 Vehicle Diagnostic And Information System (Connect Diagnostic
Tester)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAS 5052/3 diagnostic cable

Requirements

z

The respective fuses of the Motronic fuel injection and ignition system must be OK.

Fig. 2: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Battery voltage must be at least 11.5 volts.

z

All electrical consumers such as, for example, lights and rear window defroster must be switched off.

z

Parking brake must be engaged or else daylight driving lights will be switched on.

NOTE:

Fuse holder is located behind access panel at far left end of dash.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 2.0L Generic Scan Tool - New Beetle



z

For vehicles with automatic transmission, selector lever must be in position -P- or -N-.

z

If vehicle is equipped with an A/C system, it must be switched off.

z

Ground (GND) connections between engine and chassis must be OK.

z

Ignition switched off.

Work procedure

Connect diagnostic tester (VAS 5052) using (VAS 5052/3) diagnostic cable as follows:

z

Connect diagnostic cable connector to Data Link Connector (DLC) -arrow-.

Fig. 3: Locating Data Link Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Depending on the desired diagnostic mode, it is necessary to either switch on ignition or start engine. See
Selectable diagnostic modes under address word 33 - OBD .

z

If no display appears on diagnostic tester, check voltage supply.

Test box for wiring test, connecting

Recommended special tools and equipment e.g.:

Vehicles with 80-pin Engine Control Module (ECM, engine code AEG)

z

VAG1598/22 test box

NOTE:

z

Respective operation of the diagnostic tester:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 2.0L Generic Scan Tool - New Beetle
