z

Start engine and let run at idle.

z

Under address word 33, select "Diagnostic mode 1: Check measured values."

z

select desired measuring value "PID 01".

z

Observe the right 8-digit number block:

If all diagnoses have run through successfully, the 8-digit number block

Specified value: 00000000 must be displayed.

Evaluation PID 01: System status-information (right 8-digit number block:)

EVALUATION PID 01: SYSTEM STATUS-INFORMATION

If a 1 is displayed instead of a 0 in the 8-digit number block:

z

Generate readiness code. See READINESS CODE, GENERATING .

Readiness code, generating

Requirements

Meaning if display position = 0
1

2 3 4 5 6 7 8

Diagnostic function

0















Exhaust gas recirculation OK



0











Oxygen sensor heater OK

z

not available/always "0"



  0









Oxygen sensors OK

z

not available/always "0"





  0







A/C system OK

z

not available/always "0"







  0





Secondary Air Injection (AIR) system OK

z

not available/always "0"









  0



EVAP canister system (tank ventilation system) OK

z

not available/always "0"











  0

Catalytic converter heater OK

z

not available/always "0"













  0

Catalytic converter OK

z

not available/always "0"



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle



z

The respective fuses of Diesel-Direct fuel injection system must be OK.

Fig. 10: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Battery voltage must be at least 11.5 Volts.

z

All electrical consumers such as, for example, lights and rear window defroster must be switched off.

z

If vehicle is equipped with an A/C system, it must be switched off.

z

Ground (GND) connections between engine and chassis must be OK.

z

There must not be any DTCs stored in DTC memory. See DIAGNOSTIC MODE 3: CHECK DTC
MEMORY
 .

Work procedure

z

Connect diagnostic tester. See DIAGNOSTIC TESTER, CONNECTING .

z

Switch ignition on.

z

Wait 5 seconds.

z

Let engine run at idle.

z

Wait 45 seconds.

z

Perform a road test.

The following operating conditions must be met during this road test:

z

With accelerator pedal depressed completely, accelerate vehicle in 3. gear or in driving mode "3" from 50
km/h to 120 km/h.

z

Drive for 2 minutes in 4. gear or in driving mode "D" on a level driving surface at a constant vehicle
speed with an engine speed of 1700 to 1900 RPM.

NOTE:

Fuse holder is located behind access panel at far left end of dash.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle



Observe the safety precautions that apply to road tests. See SAFETY PRECAUTIONS .

z

Park vehicle and switch off ignition.

z

Wait 15 seconds.

z

Switch ignition on.

z

Wait 5 seconds.

z

Let engine run at idle.

z

Wait 45 seconds.

z

Perform a road test anew.

The following operating conditions must be met during this road test:

z

With accelerator pedal depressed completely, accelerate vehicle in 3. gear or in driving mode "3" from 50
km/h to 120 km/h.

z

Drive for 2 minutes in 4. gear or in driving mode "D" on a level driving surface at a constant vehicle
speed with an engine speed of 1700 to 1900 RPM.

Observe the safety precautions that apply to road tests. See SAFETY PRECAUTIONS .

z

Park vehicle and let engine run at idle for 3 minutes.

z

Accelerator pedal must not be operated during this time.

z

Read readiness code. See READ READINESS CODE .

If a 1 is displayed instead of a 0 in the 8-digit number block:

z

Repeat complete work procedure. See WORK PROCEDURE .

DIAGNOSTIC TROUBLE CODE (DTC) TABLES:

SAE P0xxx-DTCs

Fuel and air ratios

DIAGNOSTIC TROUBLE CODES P0100-P0108

NOTE:

z

Vehicle speed. See DIAGNOSTIC MODE 1: CHECK MEASURED VALUES ;
PID 13, Vehicle speed.

z

Engine speed. See DIAGNOSTIC MODE 1: CHECK MEASURED VALUES ;
PID 12, engine rotations per minute (RPM).

SAE-
DTC

DTC text

Corrective action



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle



DIAGNOSTIC TROUBLE CODES P0116-P0128

DIAGNOSTIC TROUBLE CODES P0181-P0183

P0100

Mass or Volume Air Flow

Circuit

z

Check Mass Air Flow (MAF) Sensor -G70-. See MASS
AIR FLOW (MAF) SENSOR, CHECKING
 .

P0101

Mass or Volume Air Flow

Circuit Range/Performance

P0102

Mass or Volume Air Flow

Circuit Low Input

P0103

Mass or Volume Air Flow

Circuit High Input

P0105

Manifold Absolute

Pressure/Barometric Pressure

Circuit

z

Check Manifold Absolute Pressure (MAP) Sensor -G71-

and Barometric Pressure (BARO) Sensor -F96-. See

MANIFOLD ABSOLUTE PRESSURE (MAP)

SENSOR AND BAROMETRIC PRESSURE (BARO)

SENSOR, CHECKING

P0106

Manifold Absolute

Pressure/Barometric Pressure

Circuit Range/Performance

P0107

Manifold Absolute

Pressure/Barometric Pressure

Circuit Low Input

P0108

Manifold Absolute

Pressure/Barometric Pressure

Circuit High Input

SAE-
DTC

DTC text

Corrective action

P0116

Engine Coolant Temperature Circuit

Range/Performance

z

Check Engine Coolant Temperature (ECT) Sensor
-G62-. See ENGINE COOLANT
TEMPERATURE (ECT) SENSOR,
CHECKING
 .

z

Check coolant regulator:

See COOLING SYSTEM COMPONENTS,
ENGINE SIDE
 .

P0117

Engine Coolant Temperature Circuit

Low

P0118

Engine Coolant Temperature Circuit

High

P0128

Coolant Thermostat (Coolant

Temperature Below Thermostat

Regulating Temperature)

z

Check coolant regulator:

See COOLING SYSTEM COMPONENTS,

ENGINE SIDE .

SAE-
DTC

DTC text

Corrective action

P0181

Fuel Temperature Sensor A Circuit

Range/Performance

z

Check Fuel Temperature Sensor -G81-. See FUEL

TEMPERATURE SENSOR, CHECKING

P0182

Fuel Temperature Sensor A Circuit

Low



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle
