Volkswagen New Beetle. Manual - part 1975





Fig. 4: Identifying VAG1598/22 Test Box (80-Pin ECM)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with 121-pin Engine Control Module (ECM, engine code AVH, AZG, BDC)

z

VAG1598/31 test box

Fig. 5: Identifying VAG1598/31 Test Box (121-Pin ECM)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirement

z

Ignition switched off.

Work procedure

z

Remove inner cover, left plenum chamber, to do this, slide center cover -1- of plenum chamber forward
out of catch and remove from instrument panel.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 2.0L Generic Scan Tool - New Beetle



Fig. 6: Removing Inner Cover, Left Plenum Chamber By Sliding Center Cover Of Plenum
Chamber Forward

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove three bolts -1-.

Fig. 7: Removing Three Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lift left cover -1- of plenum chamber in center of instrument panel (arrow A) and thereby unclip (front
edge clips, back edge clamps).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 2.0L Generic Scan Tool - New Beetle



Fig. 8: Lifting Left Cover Of Plenum Chamber In Center Of Instrument Panel And Unclip
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull cover -1- toward vehicle center out of bracket underneath A-pillar (arrow B).

z

Then disengage connector from control module and disconnect.

Vehicles with 80-pin Engine Control Module (ECM, engine code AEG)

z

Connect VAG1598/22 test box at control module wiring harness.

Fig. 9: Connecting VAG1598/22 Test Box At Control Module Wiring Harness (80-Pin ECM)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with 121-pin Engine Control Module (ECM, engine code AVH, AZG, BDC)

z

Connect VAG1598/31 test box at control module wiring harness. Engine Control Module (ECM) is not
connected.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 2.0L Generic Scan Tool - New Beetle



Fig. 10: Connecting VAG1598/31 Test Box At Control Module Wiring Harness (121-Pin ECM)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Continuation for all vehicles

When harness connectors are disconnected from the Engine Control Module (ECM) or the battery is
disconnected, all adaptation values in the control module are erased. DTC memory content will remain intact
however. If the engine is started after this, rough, uneven idle can result. In this case, the readiness code must be
generated again. See READINESS CODE, GENERATING .

Malfunction Indicator Lamp (MIL) in instrument cluster, checking

Meaning of emissions MIL

The Malfunction Indicator Lamp (MIL) lights up when emissions relevant malfunctions are recognized by the
Engine Control Module (ECM).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 2.0L Generic Scan Tool - New Beetle
