Volkswagen New Beetle. Manual - part 1809





P0222

16606

Angle Sensor 2 (G188) For Throttle Valve Drive - Signal Too

Low

P0223

16607

Angle Sensor 2 (G188) For Throttle Valve Drive - Signal Too

High

P0226

16610

Accelerator Pedal Position Sensor 1 (G79), Accelerator Pedal

Position Sensor 2 (G185) - Implausible Signal

P0230

16614

Fuel Pump Relay (J17) - Circuit Malfunction

P0261

16645

Injector Cylinder 1 (N30) - Short To Ground

P0262

16646

Injector Cylinder 1 (N30) - Short To B+

P0264

16648

Injector Cylinder 2 (N31) - Short To Ground

P0265

16649

Injector Cylinder 2 (N31) - Short To B+

P0267

16651

Injector Cylinder 3 (N32) - Short To Ground

P0268

16652

Injector Cylinder 3 (N32) - Short To B+

P0270

16654

Injector Cylinder 4 (N33) - Short To Ground

P0271

16655

Injector Cylinder 4 (N33) - Short To B+

P0300

16684

Misfire Recognized

P0301

16685

Cylinder 1 - Misfire

P0321

16705

Engine Speed Sensor (RPM) (G28), Implausible Signal Engine

Speed Sensor (RPM - G28) - No Signal

P0324

16708

Knock Sensor - Malfunction

P0327

16711

Knock Sensor 1 (G61) - Signal Too Low

P0328

16712

Knock Sensor 1 (G61) - Signal Too High

P0332

16716

Knock Sensor 2 (G66) - Signal Too Low

P0333

16717

Knock Sensor 2 (G66) - Signal Too High

P0341

16725

Camshaft Position Sensor (G40) - Implausible Signal

P0351

16735

Ignition Control Cylinder 1 - Malfunction

P0352

16736

Ignition Control Cylinder 2 - Malfunction

P0353

16737

Ignition Control Cylinder 3 - Malfunction

P0354

16738

Ignition Control Cylinder 4 - Malfunction

P0420

16804

Catalyst System - Efficiency Below Threshold

P0441

16825

EVAP, Fuel Tank Ventilation System - Flow Rate Malfunction

P0442

16826

EVAP - Small Leak Detected

P0455

16839

EVAP - Very Large Leak Detected

P0456

16840

EVAP - Very Small Leak Detected

P0501

16885

Vehicle Speed Signal - Implausible Signal

P0506

16890

Idle Speed Control - RPM Too Low

P0507

16891

Idle Speed Control - RPM Too High

P0513

16897

Immobilizer - Incorrect Code

P0568

16952

Cruise Control System Switch (E45) - Implausible Signal



2003 Volkswagen New Beetle GLS

2001-2003 ENGINE PERFORMANCE Self-Diagnostics - 2.0L - Beetle, Golf & Jetta (Engine Codes AVH & AZG)



Helpmelearn Repair Manuals



Wednesday, December 14, 2005 8:49:54 AM

Page 36

© 2004 Mitchell Repair Information Company, LLC.

P0571

16955

Brake Light Switch (F) - Implausible Signal

P0600

16984

Data Bus Drive - Missing Signal

P0601

16985

ECM (J220) - Malfunction

P0602

16986

ECM (J220) - Programming Malfunction

P0604

16988

ECM (J220) - Malfunction

P0605

16989

ECM (J220) - Malfunction

P0606

16990

ECM (J220) - Malfunction

P0638

17022

Throttle Valve Control Module (J338) - Implausible Signal

P0642

17026

Knock Sensor - ECM Malfunction

P0685

17069

Power Supply Relay (J271) - Open Circuit

P0686

17070

Power Supply Relay (J271) - Short Circuit To Ground

P0687

17071

Power Supply Relay (J271) - Short Circuit To B+

P0688

17072

Power Supply Relay (J271) - Open Load Circuit

P1103

17511

HO2 Sensor (G39) Upstream TWC - Heating Element Output Too

Low

P1105

17513

HO2 Sensor (G130) Downstream TWC - Heating Circuit Short To

B+

P1113

17521  HO2 Sensor (G39) Upstream TWC - Internal Resistance Too High

P1117

17525

HO2 Sensor (G130) Downstream TWC - Heating Circuit Short To

Ground

P1118

17526

HO2 Sensor (G130) Downstream TWC - Heating Circuit Open

P1141

17549

Load Detection - Implausible Value

P1142

17550

Load Detection - Lower Limit Not Reached

P1143

17551

Load Detection - Upper Limit Exceeded

P1145

17553

MAF sensor (G70) - Short To B+

P1152

17560

HO2 Sensor (G130) Downstream TWC, Lean Control Limit Not

Reached HO2 Sensor (G130) Downstream TWC - Control Limit

Exceeded

P1166

17574

HO2 Sensor (G130) Downstream TWC - Rich Control Limit

Exceeded

P1176

17584

HO2 Sensor (G39) Correction Upstream TWC, HO2 Sensor

(G130) Downstream TWC - Control Limit Reached

P1178

17586

HO2 Sensor (G39) Upstream TWC, Pump Current - Open Circuit

P1179

17587

HO2 Sensor (G39) Upstream TWC, Pump Current - Short To

Ground

P1180

17588

HO2 Sensor (G39) Upstream TWC, Pump Current - Short To B+

P1181

17589

HO2 Sensor (G39) Upstream TWC, Reference Voltage - Open

Circuit

P1182

17590

HO2 Sensor (G39) Upstream TWC, Reference Voltage - Short To

Ground

P1183

17591

HO2 Sensor (G39) Upstream TWC, Reference Voltage - Short To



2003 Volkswagen New Beetle GLS

2001-2003 ENGINE PERFORMANCE Self-Diagnostics - 2.0L - Beetle, Golf & Jetta (Engine Codes AVH & AZG)



Helpmelearn Repair Manuals



Wednesday, December 14, 2005 8:49:54 AM

Page 37

© 2004 Mitchell Repair Information Company, LLC.

B+

P1184

17592

HO2 Sensor (G39) Upstream TWC, ECM Ground - Open Circuit

P1185

17593

HO2 Sensor (G39) Upstream TWC, ECM Ground - Short To

Ground

P1186

17594

HO2 Sensor (G39) Upstream TWC, ECM Ground - Short To B+

P1296

17704

Malfunction In Cooling System

P1325

17733

Knock Control Cylinder 1 - Limit Reached

P1326

17734

Knock Control Cylinder 2 - Limit Reached

P1327

17735

Knock Control Cylinder 3 - Limit Reached

P1328

17736

Knock Control Cylinder 4 - Limit Reached

P1335

(2)

17743

(2)

Engine Torque Monitoring 2 - Control Limit Exceeded

P1336

17744

Engine Torque Monitoring - Control Limit Exceeded

P1337

17745

Camshaft Position Sensor (G40) - Short To Ground

P1338

17746

Camshaft Position Sensor (G40) - Open Circuit/Short To B+

P1340

17748

Camshaft Position Sensor (G40) - Engine Speed Sensor (G28),

Incorrect Allocation

P1355

17763

Ignition Activation Cylinder 1 - Open Circuit

P1356

17764

Ignition Activation Cylinder 1 - Short To B+

P1357

17765

Ignition Activation Cylinder 1 - Short To Ground

P1358

17766

Ignition Activation Cylinder 2 - Open Circuit

P1359

17767

Ignition Activation Cylinder 2 - Short To B+

P1360

17768

Ignition Activation Cylinder 2 - Short To Ground

P1361

17769

Ignition Activation Cylinder 3 - Open Circuit

P1362

17770

Ignition Activation Cylinder 3 - Short To B+

P1363

17771

Ignition Activation Cylinder 3 - Short To Ground

P1364

17772

Ignition Activation Cylinder 4 - Open Circuit

P1365

17773

Ignition Activation Cylinder 4 - Short To B+

P1366

17774

Ignition Activation Cylinder 4 - Short To Ground

P1386

(2)

17794

(2)

ECM (J220) - Malfunction

P1387

(2)

17795

(2)

ECM (J220) - Malfunction

P1388

(2)

17796

(2)

ECM (J220) - Malfunction

P1471

17879

EVAP Leak Detection Pump (V144) - Short To B+

P1472

17880

EVAP Leak Detection Pump (V144) - Short To Ground

P1473

17881

EVAP Leak Detection Pump (V144) - Open Circuit

P1475

17883

EVAP Leak Detection Pump (V144) - No Signal

P1476

17884

EVAP Leak Detection Pump (V144) - Insufficient Vacuum

P1501

17909

Fuel Pump Relay (J17) - Short To Ground

P1502

17910

Fuel Pump Relay (J17) - Short To B+



2003 Volkswagen New Beetle GLS

2001-2003 ENGINE PERFORMANCE Self-Diagnostics - 2.0L - Beetle, Golf & Jetta (Engine Codes AVH & AZG)



Helpmelearn Repair Manuals



Wednesday, December 14, 2005 8:49:54 AM

Page 38

© 2004 Mitchell Repair Information Company, LLC.

P1539

17947

Clutch Vacuum Vent Switch (F36) - Implausible Signal

P1541

17949

Fuel Pump Relay (J17) - Open Circuit

P1542

(2)

17950

(2)

Angle Sensor 1 (G187) For Throttle Valve Drive - Implausible

Signal

P1545

(2)

17953

(2)

Throttle Valve Control Malfunction

P1558

(2)

17966

(2)

Throttle Valve Drive (186) - Circuit Malfunction

P1559

(2)

17967

(2)

Throttle Valve Control Module (J338) - Malfunction In Basic

Setting

P1564

(2)

17972

(2)

Throttle Valve Control Module (J338) - Voltage Too Low During

Basic Setting

P1568

(2)

17976

(2)

Throttle Valve Control Module (J338) - Mechanical Malfunction

P1570

17978

ECM (J220) - Blocked

P1579

(2)

17987

(2)

Throttle Valve Control Module - Adaptation Not Started

P1602

18010

Voltage Supply Terminal 30 (B+) - Voltage Supply Too Low

P1603

18011

ECM (J220) - Malfunction

P1609

18017

Crash Signal From Airbag Control Module

P1612

18020

ECM (J220) - Incorrectly Coded

P1626

18034

Drivetrain Data Bus - No Signal From Transmission Control

Module (J217)

P1630

(2)

18038

(2)

Accelerator Pedal Position Sensor 1 (G79) - Signal Too Low

P1631

(2)

18039

(2)

Accelerator Pedal Position Sensor 1 (G79) - Signal Too High

P1633

(2)

18041

(2)

Accelerator Pedal Position Sensor 2 (G185) - Signal Too Low

P1634

(2)

18042

(2)

Accelerator Pedal Position Sensor 2 (G185) - Signal Too High

P1636

18044

Drivetrain Data Bus - No Signal From Airbag Control Module

(J234)

P1639

(2)

18047

(2)

Accelerator Pedal Position Sensor 1 (G79) Accelerator Pedal

Position Sensor 2 (G185) - Implausible Signal

P1648

18056

Drivetrain Data Bus - Malfunction

P1650

18058

Drivetrain Data Bus - No Signal From Instrument Cluster Control

Module (J285)

P1682

18090

Drivetrain Data Bus - Implausible Signal From ABS Control

Module (J104)

P1683

18091

Drivetrain Data Bus - Implausible Signal From Airbag Control

Module (J234)

P1696

18104

Data Bus - Implausible Signal From Steering Column Electronics

(1)

No Fault Code, Displays "No DTC recognized" (On VAG and VAS Scan Tools). If
no fault codes are present but vehicle is malfunctioning, see appropriate SYSTEM &
COMPONENT TESTING article and perform appropriate tests.

(2)

When this DTC is stored, Malfunction Indicator Light (MIL) and Electronic Power



2003 Volkswagen New Beetle GLS

2001-2003 ENGINE PERFORMANCE Self-Diagnostics - 2.0L - Beetle, Golf & Jetta (Engine Codes AVH & AZG)



Helpmelearn Repair Manuals



Wednesday, December 14, 2005 8:49:54 AM

Page 39

© 2004 Mitchell Repair Information Company, LLC.
