Fig. 4: Vag 1551/1552 Scan Tool Display - Cruise Control System (4 Of 4)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Refer to the following engine specific tables to interpret values in display fields 2 - 4:

z

1.8 Liter Turbo (codes APH & AWV). See 1.8 LITER TURBO (CODES APH, AWV & AWP)
& 2.0 LITER (CODES AVH & AZG)
 .

z

1.9 Liter TDI. See 1.9 LITER TDI .

z

2.0 Liter (code AEG). See 2.0 LITER (CODE AEG) .

z

2.0 Liter (codes AVH & AZG). See 1.8 LITER TURBO (CODES APH, AWV & AWP) & 2.0
LITER (CODES AVH & AZG)
 .

1.8 Liter Turbo (codes APH, AWV & AWP) & 2.0 Liter (codes AVH & AZG)

1.8 LITER TURBO (CODES APH, AWV & AWP) & 2.0 LITER (CODES AVH & AZG)
SPECIFICATION


NOTE:

z

The road speed signal input to the ECM for cruise control function
can be confirmed by performing a road test and observing that the
km/h value indicated in display field 1 changes.

z

Always observe the appropriate safety precautions during road test.

Display
Group

Display

Field

Designation

Test

Conditions

Display

Corrective Actions

66

2

Clutch vacuum

vent valve -F36-

and Brake switch -

F47-

Clutch and

brake not

depressed

1000

z

Check for open/short circuit in

wiring and connections to -F36-

and/or -F47- using wiring

diagram

z

Checking -F36- and/or -F47-:

See "ADDITIONAL SIGNALS,

CHECKING ".







Brake

1011





2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Cruise Control - New Beetle



2.0 Liter (code AEG)

2.0 LITER (CODE AEG) SPECIFICATION

depressed







Clutch

depressed

1100





4

Cruise control

switch -E45-

-E45- in OFF

position

0000

z

Check for open/short circuit in

wiring and connections to -E45-,

-E227- and Engine Control

Module (ECM) using wiring

diagram







-E45- in OFF

position before

switch point

0001









-E45- in ON

position

0011









-E45- in RES

position

1011







Button for cruise

control SET -

E227-

-E45- in ON

position

-E227- SET

button

depressed

0111



Display
Group

Display

Field

Designation

Test

Conditions

Display

Corrective Actions

66

2

Clutch vacuum

vent valve -F36-

and Brake switch -

F47-

Clutch and

brake not

depressed

1000

z

Check for open/short circuit in

wiring and connections to -F36-

and/or -F47- using wiring

diagram

(2)

z

Checking -F36- and/or -F47-:

See "ADDITIONAL SIGNALS,

CHECKING ".







Brake

depressed

1111









Clutch

depressed

1110





4

Cruise control

switch -E45-

(1)

-E45- in OFF

position

0011

z

Check for open/short circuit in

wiring and connections to -E45-,

-E227- and Engine Control

Module (ECM) using wiring

diagram







-E45- in OFF

position before

0010





2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Cruise Control - New Beetle



1.9 Liter TDI

1.9 LITER TDI SPECIFICATION

switch point







-E45- in ON

position

0000









-E45- in RES

position

1000







Button for cruise

control SET -

E227-

-E45- in ON

position

-E227- SET

button

depressed

0100



(1)

In order to check -E45- on 1998 models with automatic transmission, it may be necessary to first
perform a test drive and exceed 30 km/h (approx. 19 mph). Perform test at idle A drive range other
than 1 or R must then be selected at idle with parking brake engaged.

(2)

The power supply circuit to -F36- and -F47- was changed beginning with m.y. 1999. Always use
appropriate wiring diagram.

Display
Group

Display

Field

Designation

Test

Conditions

Display

Corrective Actions

06

2

Clutch vacuum

vent valve -F36-

and Brake switch

-F47-

Clutch and

brake not

depressed

000

z

Check for open/short circuit in

wiring and connections to -F36-

and/or -F47- using wiring diagram







Brake

depressed

0 1 1









Clutch

depressed

1 00







-

Clutch and

brake

depressed

1 1 1





3

Cruise control

switch -E45-

(1)

-E45- in OFF

position

000000

z

Check for open/short circuit in

wiring and connections to -E45-, -

E227- and Diesel Direct Fuel

injection Control Module (ECM)

using wiring diagram





-

-E45- in OFF

position before

switch point

000001









-E45- in ON

position

000011









-E45- in RES

position

001011





2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Cruise Control - New Beetle



CRUISE CONTROL SYSTEM - TDI ENGINES, ACTIVATING

If a Diesel Direct Injection Engine Control Module (ECM) has been replaced, it may be necessary to activate
the cruise control function in the new ECM. Check system status and activate if necessary using the following
procedure.

z

Connect VAG 1551/1552 Scan Tool.

See VAG 1551 SCAN TOOL (ST), CONNECTING, SELECTING FUNCTIONS & CHECKING
CONTROL MODULE VERSIONS
 .

z

Switch on ignition

z

Press buttons 0 and 1 to select "Engine electronics" address word 01.

Indicated on display (example only)





Button for cruise

control SET -

E227-

-E45- in ON

position

E227- SET

button

depressed

000111





4

System status

System

activated, -

E45- in ON

position

1









System

activated, -

E45- in OFF

position

0









System not

activated

255

z

Activate cruise control, See

CRUISE CONTROL SYSTEM

- TDI ENGINES,

ACTIVATING

(1)

In order to check -E45- on 1998 models with automatic transmission, it may first be necessary to
perform a test drive and exceed 30 km/h (approx. 19 mph). A drive range other than 1 or R must then
be selected at idle with parking brake engaged.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Cruise Control - New Beetle
