z Charge air cooler/intake manifold z To remove, remove right headlight 3. O-ring z Replace if damaged 4. Intake Air Temperature (IAT) Sensor -G72- z Vehicles of model year 2000 and up at charge air cooler 5. 5 Nm 6. Connection hose z Connection pipe/intake manifold 7. Connection hose z Charge air pipe/turbocharger 8. 10 Nm 9. Charge air pipe 10. Connection hose 11. Bracket 12. Charge air cooler Fig. 4: Identifying Parts Of Charge Air Cooler Components Line connections of turbocharger
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE PERFORMANCE Turbocharger, G-Charger - New Beetle
|
