z When the system is open: Do not work with compressed air if this can be avoided. Do not move vehicle Technical data TECHNICAL DATA SPECIFICATION FUEL INJECTION SYSTEM COMPONENTS, CHECKING Heated Oxygen Sensor (HO2S) for oxygen sensor before Three Way Catalytic Converter (TWC), checking Special tools, test equipment and auxiliary items z VAG 1551 scan tool or VAG 1552 mobile scan tool with VAG 1551/3B cable z VAG 1598/31 test box z VAG 1526 A or Fluke 83 multimeter z VAG 1594 adapter set z Electrical Wiring Diagram Test conditions Engine code AWP AWV Idle check (at normal operating temperature) Idle speed (1) RPM Manual transmission 760 to 810 (1) 760 to 810 (1) Automatic transmission 700 to 750 (1) 700 to 750 (1) Motronic Engine Control Module (ECM) -J220- (2) System Motronic ME7.5 Motronic ME7.5 Part number (3) Manual transmission 1C0 906 032 06A 906 032 GA Automatic transmission
06A 906 032 GB Governed speed RPM from approx. 6800 from approx. 6800 (1) Not adjustable (2) Replacing Motronic Engine Control Module (ECM) -J220-, see MOTRONIC ENGINE (3) For latest part number for Engine Control Module: See Parts catalog. NOTE: z Raise vehicle to reach oxygen sensor connector z Only gold-plated terminals must be used to repair the terminals in the
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE PERFORMANCE Multiport Fuel Injection (MFI) , 1.8L AWP, AWV - New Beetle
|
