Volkswagen New Beetle. Manual - part 1574





Fig. 10: Exploded View Of Intake Manifold Lower Parts (Engine Code AEG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine codes AVH, AZG



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



1. Fuel pressure regulator

z

Checking. See FUEL PRESSURE REGULATOR AND HOLDING PRESSURE, CHECKING

2. O-ring

z

Replace if damaged

3. Vacuum hose

z

To intake manifold, upper part

4. Air pipe

5. Air hose

z

For air shrouded injectors

6. O-ring

z

Replace if damaged

z

Coat with thin layer of clean engine oil before installing

7. Injectors -N30- ...-N33-

z

Checking injectors for leaks and quantity injected. See COMPONENTS, CHECKING

z

Air shrouded

8. 20 N.m

9. Intake manifold lower part

10. Gasket

z

Replace

11. Fuel distributor

12. 10 N.m

13. Retaining clip

z

Check for secure seating

14. Wiring guide

z

Clipped onto fuel distributor

15. Connection, return line

16. Connection, supply line

17. To intake air duct

18. Retaining clip

z

Check for secure seating

NOTE:

The following list refers to items in Fig. 11 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 11: Exploded View Of Intake Manifold Lower Parts (Engine Codes AVH And AZG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine code BDC

1. Fuel rail with injectors

z

Disassembling and assembling. See FUEL RAIL WITH INJECTORS, DISASSEMBLING
AND ASSEMBLING


2. Vacuum hose

z

To intake manifold upper part. See Fig. 9 , item -10-

3. Cable channel

4. Seal

NOTE:

The following list refers to items in Fig. 12 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

Replace if damaged

5. Intake manifold lower part

z

With variable intake manifold change-over

6. To vacuum positioning element

z

On front side of intake manifold lower part

7. 3 N.m

8. Intake Manifold Tuning (IMT) valve -N261-

9. 5 N.m

10. Washer

11. 25 N.m

12. From intake manifold upper part

z

See Fig. 9 , item -12-

13. Seal

z

Replace

14. Connector, 2-pin

z

For Knock Sensor (KS) 1 -G61-

15. Connector, 3-pin

z

For Camshaft Position (CMP) sensor -G40-

16. Connector, 2-pin

z

For Intake manifold change-over valve -N156-



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)
