Volkswagen New Beetle. Manual - part 1573





Fig. 8: Exploded View Of Intake Manifold Upper Part (Engine Code AVH, AZG And BEV)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine codes BDC, BGD



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



1. 8 N.m

z

Observe different lengths of securing bolts

2. Throttle valve control module -J338-

z

When replacing, adapt (match) engine control module to throttle valve control module. See
COMPONENTS AND FUNCTIONS, ADAPTING

3. Seal

z

Replace if damaged

4. Pressure relief valve

z

Protects intake manifold from damage caused by excess pressures

5. Vacuum hose

z

From PCV heating element -N79-. See Fig. 3 , item - 10 -

6. Shaped hose

z

From PCV heating element -N79- or cylinder head cover. See ENGINES WITH ALUMINUM
CYLINDER HEAD COVER
 , item - 5 -

7. 5 N.m

8. Intake manifold upper part

z

With variable intake manifold change-over

z

Removing and installing. See INTAKE MANIFOLD UPPER PART, REMOVING AND
INSTALLING


9. Spreader rivet

10. Vacuum hose

Only engine code BDC

z

From fuel pressure regulator. See Fig. 15 , item -14-

11. To vacuum positioning element

z

On underside of intake manifold upper part

12. To T-piece

z

See Fig. 12 , item -12-

13. Intake manifold change-over valve -N156-

14. 8 N.m

15. Rubber bushing

16. Warm air collector plate

z

With intake manifold support

z

With mounting for combi-valve

17. To Leak Detection Pump (LDP) -V144-

18. To brake servo

NOTE:

The following list refers to items in Fig. 9 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 9: Exploded View Of Intake Manifold Upper Parts (Engine Code BDC And BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

INTAKE MANIFOLD LOWER PART, DISASSEMBLING AND ASSEMBLING

Engine code AEG

z

Engine codes AVH, AZG. See ENGINE CODES AVH, AZG

z

Engine code BDC. See ENGINE CODE BDC

z

Engine code BEV. See ENGINE CODE BEV

z

Engine code BGD. See ENGINE CODE BGD

1. Retaining clip

NOTE:

The following list refers to items in Fig. 10 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

Ensure it is securely seated

2. Strainer

3. Fuel pressure regulator

z

Fuel pressure regulator and residual pressure, checking. See FUEL PRESSURE REGULATOR
AND HOLDING PRESSURE, CHECKING
 .

4. O-ring

z

Replace if damaged.

5. Fuel injectors -N30- to -N33-

z

Checking injectors for leaks and quantity injected. See COMPONENTS, CHECKING

6. Intake manifold lower section

7. 10 N.m

8. Fuel rail



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)
