1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 3: Identifying Injection System Component Locations (Engine Codes BDC And BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.


Engine code BEV

Components A, B and C are not shown in the illustration.

A. Brake pedal switch -F47- or Brake light switch -F-

z

Together in one housing, in footwell

B. Throttle Position (TP) sensor -G79- and Sender -2- for accelerator pedal position -G185-

z

In footwell on accelerator pedal:

C. Clutch vacuum vent valve switch -F36-

z

In footwell

D. Fuel pressure regulator

z

Together with fuel filter

1. EVAP canister purge regulator valve -N80-

z

EVAP system. See EVAP SYSTEM COMPONENTS, SERVICING

2. Supply line

z

Secure with spring-type clips

3. Camshaft Position (CMP) sensor -G40-

z

Below upper toothed belt guard

4. Intake manifold

Upper part:

z

Disassembling and assembling. See INTAKE MANIFOLD UPPER PART, DISASSEMBLING
AND ASSEMBLING


Lower part:

z

Disassembling and assembling. See INTAKE MANIFOLD LOWER PART,
DISASSEMBLING AND ASSEMBLING


5. Throttle valve control module -J338-

z

When replacing, adapt (match) engine control module to throttle valve control module. See
COMPONENTS AND FUNCTIONS, ADAPTING

z

Gold plated contacts

6. Combination valve

NOTE:

The following list refers to items in Fig. 4 .

NOTE:

The following list refers to items in Fig. 4 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

Secondary air system. See SECONDARY AIR SYSTEM

7. Positive Crankcase Ventilation (PCV) heating element -N79-

z

For crankcase breather

z

Check heating element voltage supply between contacts 1 and 2 with engine running, Specification:
min. 11.5V

8. 81-pin connector

z

Only disconnect or connect with ignition switched off

z

Release to disconnect

9. Motronic Engine Control Module -J220-

z

On replacement, control module must be matched to electronic immobilizer. See COMPONENTS
AND FUNCTIONS, ADAPTING


z

Location: Under left side inner plenum chamber cover in passenger compartment

z

Replacing. See ENGINE CONTROL MODULE

10. 40-pin connector

z

Only disconnect or connect with ignition switched off

z

Release to disconnect

11. Protective housing for relays

z

Secondary Air Injection (AIR) pump relay -J299-

z

Motronic ECM power supply relay -J271-

z

Relay locations in protective housing Location of 6-pin connector -1- for heated oxygen sensor

12. Engine Coolant Temperature (ECT) sensor -G62-

z

Green

z

Gold plated contacts

z

For engine control module

z

With ECT sensor -G2-

z

Release pressure in cooling system if necessary before removing components

13. Air cleaner

z

Disassembling and assembling. See AIR CLEANER, DISASSEMBLING AND ASSEMBLING

14. Mass Air Flow (MAF) sensor -G70- with Intake Air Temperature (IAT) sensor -G42-

z

Gold plated contacts

15. Main fuses

z

For additional protection

16. Ignition coils with final output stages -N70-, -N127-, -N291-, -N292-

z

See ENGINE CODES AVH, AZG, BDC, BEV, BGD , item - 2 -

17. 10 N.m

18. Engine speed (RPM) sensor -G28-

19. Secondary Air Injection (AIR) pump motor -V101-

z

Secondary air system. See SECONDARY AIR SYSTEM



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



20. Injector -N30-...- N33-

z

Checking quantity injected and for leaks. See COMPONENTS, CHECKING

z

Air shrouded

21. Knock Sensor (KS) 2 -G66-

z

Gold plated contacts

z

Next to ignition transformer

z

See ENGINE CODES AVH, AZG, BDC, BEV, BGD , item - 7 -

22. Knock Sensor (KS) 1 -G61-

z

Gold plated contacts

z

See ENGINE CODES AVH, AZG, BDC, BEV, BGD , item - 5 -

23. 4-pin connector

z

Brown: for O2S Behind TWC -G130- and O2S heater 1 -Z29-

z

Location: On right underside of vehicle. See Location of 4-pin connector -1- for oxygen sensor
behind catalytic converter


24. Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC)-G130-, 50 N.m

z

When replacing erase fault memory. See ENGINE CONTROL MODULE FAULT MEMORY,
INTERROGATING AND ERASING


z

Grease only threads with hot bolt paste G 052 112 A3. Grease must not get into slots on sensor
body

z

Remove and install with 3337

25. 6-pin connector

z

Black: for HO2S -G39- and O2S heater -Z19-

z

Location: On right underside of vehicle. See Location of 6-pin connector -1- for heated oxygen
sensor


26. Heated Oxygen Sensor (HO2S) -G39-, 50 N.m

z

When replacing erase fault memory. See ENGINE CONTROL MODULE FAULT MEMORY,
INTERROGATING AND ERASING


z

Location: In exhaust manifold

z

Grease only threads with hot bolt paste G 052 112 A3. Grease must not get into slots on sensor
body

z

Remove and install with 3337

27. 3-pin connector

z

For Engine speed (RPM) sensor -G28-
