Fig. 1: Identifying Injection System Component Locations (Engine Code AEG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine codes AVH, AZG

Components A, B and C are not shown in the illustration.

A. Brake pedal switch -F47- or Brake light switch -F-

z

Together in one housing, in footwell

B. Throttle Position (TP) sensor -G79- and Sender -2- for accelerator pedal position -G185-

z

In footwell on accelerator pedal:

C. Clutch vacuum vent valve switch -F36-

z

In footwell

1. EVAP canister purge regulator valve -N80-

z

EVAP system. See EVAP SYSTEM COMPONENTS, SERVICING

NOTE:

The following list refers to items in Fig. 2 .

NOTE:

The following list refers to items in Fig. 2 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



2. Camshaft Position (CMP) sensor -G40-

z

Below upper toothed belt guard

3. Intake manifold

Upper part:

z

Disassembling and assembling. See INTAKE MANIFOLD UPPER PART, DISASSEMBLING
AND ASSEMBLING


Lower part:

z

Disassembling and assembling. See INTAKE MANIFOLD LOWER PART,
DISASSEMBLING AND ASSEMBLING


4. Throttle valve control module -J338-

z

When replacing, adapt (match) engine control module to throttle valve control module. See
COMPONENTS AND FUNCTIONS, ADAPTING

z

No cable disc for accelerator cable as this is an electronic accelerator system

z

6-pin connector

z

Gold plated contacts

5. Heated Oxygen Sensor (HO2S) -G39-, 50 N.m

z

Location: In exhaust manifold

z

Grease only threads with hot bolt paste G 052 112 A3. Grease must not get into slots on sensor
body

z

Remove and install with 3337

z

When replacing erase fault memory. See ENGINE CONTROL MODULE FAULT MEMORY,
INTERROGATING AND ERASING
 .

6. 6-pin connector

z

Black: for Heated Oxygen Sensor (HO2S) -G39- and Oxygen Sensor (O2S) heater -Z19-

z

Contacts gold plated

z

Location: On right underside of vehicle. See Location of 6-pin connector -1- for heated oxygen
sensor
 .

7. Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC)-G130-, 50 N.m

z

Location: in rear of catalytic converter

z

Grease only threads with hot bolt paste G 052 112 A3. Grease must not get into slots on sensor
body

z

Remove and install with 3337

z

When replacing erase fault memory. See ENGINE CONTROL MODULE FAULT MEMORY,
INTERROGATING AND ERASING
 .

8. 4-pin connector

z

Brown: for O2S Behind TWC -G130- and O2S heater 1 -Z29-



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

Connector contacts 3 and 4 are gold-plated

z

Location: On right underside of vehicle. See Location of 4-pin connector -1- for oxygen sensor
behind catalytic converter
 .

9. 81-pin harness connector

z

Only disconnect or connect with ignition switched off

z

Release to disconnect

10. 40-pin harness connector

z

Only disconnect or connect with ignition switched off

z

Release to disconnect

11. Motronic Engine Control Module (ECM) -J220-

z

On replacement, control module must be matched to electronic immobilizer. See COMPONENTS
AND FUNCTIONS, ADAPTING
 .

z

Location: below inner cover of plenum chamber, left side in passenger compartment

z

Engine Control Module (ECM), replacing. See ENGINE CONTROL MODULE .

12. Mass Air Flow (MAF) sensor -G70- with Intake Air Temperature (IAT) sensor -G42-

z

Gold plated contacts

13. Protective housing for relays

z

Secondary Air Injection (AIR) pump relay -J299-

z

Motronic ECM power supply relay -J271-

z

Relay locations in protective housing. See Location of 6-pin connector -1- for heated oxygen
sensor
 .

14. Air cleaner

z

Disassembling and assembling. See AIR CLEANER, DISASSEMBLING AND
ASSEMBLING
 .

15. Main fuses

z

For additional protection

16. Positive Crankcase Ventilation (PCV) heating element -N79-

z

For crankcase breather

z

Check heating element voltage supply between contacts 1 and 2 with engine running, Specification:
min. 11.5 V

17. Engine Coolant Temperature (ECT) sensor -G62-

z

Green

z

Gold plated contacts

z

For engine control module

z

With ECT sensor -G2-

z

Release pressure in cooling system if necessary before removing components

18. Ignition coils with power output stage -N70-, -N127-, -N291-, -N292-

z

See ENGINE CODES AVH, AZG, BDC, BEV, BGD , item. - 2 -



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



19. Injectors -N30-...-N33-

z

Air shrouded

z

Checking quantity injected and for leaks. See COMPONENTS, CHECKING

20. 10 N.m

21. Engine speed (RPM) sensor -G28-

22. O-Ring

z

Replace if damaged

23. 20 N.m

z

Tightening torque influences function of knock sensor

24. Knock Sensor (KS) 2 -G66-

z

Black: 2-pin

z

Gold plated contacts

z

Next to ignition transformer

25. 2-pin connector

z

For Knock Sensor (KS)2 -G66-

z

Black

z

Mark connector before disconnecting

26. Secondary Air Injection (AIR) pump motor -V101-

z

Secondary air system. See SECONDARY AIR SYSTEM

27. Knock Sensor (KS) 1 -G61-

z

Black: 2-pin

z

Gold plated contacts

28. 2-pin connector

z

For Knock Sensor (KS) 1 -G61-

z

Black

z

Mark connector before disconnecting

29. Fuel pressure regulator

z

Checking. See FUEL PRESSURE REGULATOR AND HOLDING PRESSURE,
CHECKING
 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)
