location. If test and measuring instruments are operated from front passenger's seat and the vehicle is involved in z Erase engine control module fault memory because pulling connectors off injector will have caused a z Generate readiness code if fault memory has been erased. See COMPONENTS AND FUNCTIONS, TEST DATA, SPARK PLUGS SPARK PLUGS TEST DATA Engine code AEG AVH, AZG, BEV BDC, BGD Firing order 1-3-4-2 1-3-4-2 1-3-4-2 Spark Plugs (1) , (2) VW 101 000 033 AA 101 000 062 AB 101 000 062 AB Manufacturer's designation BKR6ET-10 PZFR5D-11 PZFR 5D-11 Electrode gap 0.9 to 1.1 mm (0.035 to 0.043 in.) 1.0 to 1.1 mm 1.0 to 1.1 mm Torque setting 30 N.m (22 ft lb) 25 N.m 25 N.m (1) For spark plug change intervals, see maintenance schedule in owners manual. (2) Use tool T10112 for disconnecting and connecting spark plug connector. Remove and install spark
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Ignition Glow Plug System - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)
|
