Volkswagen New Beetle. Manual - part 1534





Fig. 3: Disconnecting Pin Harness Connector From Ignition Coil Power Output Stage (Engine Code
AEG)

Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Ignition Glow Plug System - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Engine codes AVH, AZG, BDC, BEV, BGD

z

Disconnect 6-pin connector from ignition coil with final output stage (arrow).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Ignition Glow Plug System - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Ignition Glow Plug System - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 4: Disconnecting Pin Connector From Ignition Coil With Final Output Stage (Engine codes
AVH, AZG, BDC, BEV, BGD)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Continuation for all engines

z

Pull fuse No. 32 out of fuse holder. Fuse holder is located under access panel at far left end of dash.

Fig. 5: Identifying Fuse No. 32
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Observe following if test and measuring instruments are required during a road test:

z

Test and measuring instruments must be secured to rear seat and operated by an assistant from this

NOTE:

Removing fuse 32 interrupts the voltage supply to the injectors.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Ignition Glow Plug System - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)
