Connect diode test lamp to

terminals 2 + 3 of disconnected connector.

Fig. 16: Identifying 4-Pin Harness Connector Terminals (Engine Code APH)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with engine code AWP, AWV

z

Connect diode test lamp to

terminals 2 + 3 of disconnected connector.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle



Fig. 17: Identifying 4-Pin Harness Connector Terminals (Engine Code AWP, AWV)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Continuation for all vehicles

z

Operate starter and test ignition signal from Engine Control Module (ECM).

LED should flicker.

z

Switch ignition off.

If LED flickers and voltage supply is OK:

z

Replace ignition coils with power output stage:

z

Vehicles with engine code APH, see item 2 .

z

Vehicles with engine code AWP, AWV, see item 2 .

z

Erase DTC memory of Engine Control Module (ECM), see DIAGNOSTIC MODE 4:
RESET/ERASE DIAGNOSTIC DATA
 .

z

generate readiness code, see READINESS CODE, GENERATING .

If LED does not flicker:

z

Check wires, see CHECKING WIRING

Checking wiring



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle



z

Connect test box to control module wiring harness, see CONNECT TEST BOX FOR WIRING TEST

Vehicles with engine code APH

z

Check wires between test box and 4-pin connector for open circuit according to wiring diagram.

Cylinder 1 terminal 3 + socket 102

Cylinder 2 terminal 3 + socket 95

Cylinder 3 terminal 3 + socket 103

Cylinder 4 terminal 3 + socket 94

Wire resistance: max. 1.5 ohm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle



Fig. 18: Identifying 4-Pin Harness Connector Terminals (Engine Code APH)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with engine code AWP, AWV

z

Check wires between test box and 4-pin connector for open circuit according to wiring diagram.

Cylinder 1 terminal 3 + socket 102

Cylinder 2 terminal 3 + socket 95

Cylinder 3 terminal 3 + socket 103



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle
