Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Also check wires for short circuit to each other.

Specified value:INFINITY ohm

If no malfunctions are found in the wires and there was voltage between terminals 1 + 3:

z

Replace Camshaft Position (CMP) sensor:

z

Vehicles with engine code APH, see item 7 .

z

Vehicles with engine code AWP, AWV, see item 7 .

z

Erase DTC memory of Engine Control Module (ECM), see DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA
 .

z

generate readiness code, see READINESS CODE, GENERATING .

If no malfunctions are found in wires and there was no voltage between terminals 1 + 3:

z

Replace Engine Control Module (ECM), see REPLACING ENGINE CONTROL MODULE (ECM) .

Ignition coils with power output stages, checking

Recommended special tools and equipment

z

VAG1526 multimeter or VAG1715 multimeter

z

VAG1527 voltage test lamp

z

VAG1594 connector test kit

z

Wiring diagram

Test requirements

z

Respective fuses must be OK.

z

Fuel Pump (FP) Relay -J17- must be OK. Fuse box is located behind access panel at far left end of dash.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle



Fig. 10: Identifying Fuses Box
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Battery voltage must be at least 11.5 volts.

z

All electrical consumers such as, for example, lights and rear window defroster must be switched off.

z

Parking brake must be engaged or else daylight driving lights will be switched on.

z

If vehicle is equipped with an A/C system, it must be switched off.

z

Ground (GND) connections between engine and chassis must be OK.

z

Engine speed (RPM) sensor must be OK, checking, see CHECK ENGINE SPEED (RPM) SENSOR .

z

Camshaft Position (CMP) sensors must be OK, checking, see CHECK CAMSHAFT POSITION
(CMP) SENSOR
 .

z

Ignition switched off.

Test sequence



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle



Checking voltage supply

Vehicles with engine code APH

z

Disconnect 4-pin connector -2- from ignition coil -1- to be checked.

Fig. 11: Disconnecting 4-Pin Connector From Ignition Coil (Engine Code APH)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Measure supply voltage between terminals 1 + 2 and 1 + 4 of disconnected connector using the
multimeter.

z

Switch on ignition.

Specified value: at least 11.5 V



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle



z

Switch ignition off.

If there is no voltage:

z

Check wire between 4 -pin connector terminal 1 and Motronic Engine Control Module (ECM) Power
Supply Relay (main relay) for open circuit according to wiring diagram.

Wire resistance: max. 1.5 ohm

z

Check wires between 4 -pin connector and Ground (GND) for open circuit according to wiring diagram.

Terminal 2 and Ground (GND)

Terminal 4 and Ground (GND)

Wire resistance: max. 1.5 ohm

Fig. 12: Identifying 4-Pin Harness Connector Terminals (Engine Code APH)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L Generic Scan Tool - New Beetle
