Fig. 1: Identifying V.A.G 1526 Manual Multimeter
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

V.A.G 1594 A Adapter set



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Ignition Glow Plug System - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 2: Identifying V.A.G 1594 A Adapter Set
Courtesy of VOLKSWAGEN OF AMERICA, INC.

REQUIREMENTS

z

Stripe fuse for glow plugs in fuse holder/battery OK

z

Battery voltage must be at least 11.5 V.

z

All electrical consumers, e.g. lights and rear window defogger, must be switched off.

z

Diesel Direct Fuel Injection (DFI) Engine Control Module (ECM) -J248- OK

WORK SEQUENCE

z

Remove connector on coolant temperature sensor. See DIESEL DIRECT INJECTION SYSTEM,
COMPONENT LOCATION OVERVIEW
 .

NOTE:

By pulling off the connector, the engine condition "cold " is simulated and
when the ignition is switched on the corresponding preheating process is



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Ignition Glow Plug System - New Beetle, 1.9L 4-Cyl. - BEW



z

Disconnect glow plug connectors from glow plugs.

z

Connect multimeter to measure voltage between a glow plug connector and vehicle Ground (GND).

z

Switch on ignition.

For approx. 20 seconds, approx. battery voltage must appear.

z

If no voltage is present:

See Vehicle Diagnosis, Testing and Information System VAS 5051

See appropriate System Wiring Diagram article

GLOW PLUGS, CHECKING

Special tools and equipment

z

3220 Jointed wrench

performed.

NOTE:

z

Verify that the glow plug (ceramic) - Part No. N 105 916 01 - was well
packed and the glow plug is not broken or fractured.

z

Handle the glow plugs with extreme care, do not bump or drop them.

z

When installing, first tighten glow plugs by hand and then use the special
tool to tighten to the appropriate torque.

z

NEVER use a glow plug that has been dropped or hit, since it could be
fractured and can damage the engine!

z

Observe rules for cleanliness. See RULES FOR CLEANLINESS .

z

Verify that glow plug is correct and not damaged BEFORE starting the
engine whenever installing a glow plug, See GLOW PLUGS, CHECKING .

z

If the glow plug is broken, remove it and remove the broken fragment(s)
from the engine BEFORE starting the engine. Otherwise engine damage
can occur!

CAUTION: Part numbers are for reference only. Always check with your Parts Dept.

for the latest information.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Ignition Glow Plug System - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 3: Identifying 3220 Jointed Wrench
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

V.A.G 1594 A Adapter set

z

V.A.G 1527 Diode test lamp

Requirements

z

Stripe fuse for glow plugs in fuse holder/battery OK

z

Battery voltage must be at least 11.5 V.

z

All electrical consumers, e.g. lights and rear window defogger, must be switched off.



2003 Volkswagen New Beetle GLS
