Volkswagen New Beetle. Manual - part 1495





9. Fuel filter

z

Installed position: Arrow points in direction of flow

10. EVAP canister purge regulator valve -N80-*/**

z

On right in engine compartment above wheel housing liner

z

Installed position: Arrow points in direction of flow

z

Valve will be activated by engine control module (pulsed)

11. Test union

z

Not installed on all models

12. Gravity valve

13. Pressure retention valve

z

For fuel tank breather

z

Checking. See Checking Pressure Retention Valve

14. Change-over valve

z

Check. See Checking Change-Over Valve

15. EVAP canister

z

In right rear wheel housing, behind wheel housing liner

16. Leak Detection Pump (LDP) -V144-*/**

z

In right rear wheel housing, behind wheel housing liner

z

Valve will be activated by engine control module (pulsed)

17. Air filter for leak detection pump



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 49: Hose Routing Diagram Of Evaporative Emissions (EVAP) System (Engine Code BDC)
Courtesy of VOLKSWAGEN OF AMERICA, INC.


Engine codes BEV, BGD

1. Tank flap unit

2. Fuel tank

z

When removing, support with engine/transmission jack V.A.G 1383 A

z

Removing and installing. See FUEL TANK, REMOVING AND INSTALLING

3. Fuel delivery unit

z

Removing and installing. See FUEL DELIVERY UNIT, REMOVING AND INSTALLING

4. Intake hose

5. Throttle valve control module -J338-

6. Intake manifold upper part

7. Fuel rail with injectors

8. Fuel filter

z

Installed position: Arrow points in direction of flow

z

With fuel pressure regulator

9. EVAP canister purge regulator valve -N80-

z

On right in engine compartment above wheel housing liner

z

Installed position: Arrow points in direction of flow

z

Valve will be activated by engine control module (pulsed)

10. Gravity valve

11. Pressure retention valve

z

For fuel tank breather

z

Checking. See Checking Pressure Retention Valve

12. Change-over valve

z

Check. See Checking Change-Over Valve

13. EVAP canister

z

In right rear wheel housing, behind wheel housing liner

14. Leak Detection Pump (LDP) -V144-

z

In right rear wheel housing, behind wheel housing liner

z

Valve will be activated by engine control module (pulsed)

15. Air filter for leak detection pump

NOTE:

The following list refers to items in Fig. 50 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 50: Hose Routing Diagram Of Evaporative Emissions (EVAP) System (Engine Codes BEV, BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



1998-2004 ENGINE

Ignition Glow Plug System - New Beetle, 1.9L 4-Cyl. - BEW

GLOW PLUG SYSTEM, CHECKING

SPECIAL TOOLS AND EQUIPMENT

z

V.A.G 1526 Manual multimeter

NOTE:

z

Verify that the glow plug (ceramic) - Part No. N 105 916 01 - was well
packed and the glow plug is not broken or fractured.

z

Handle the glow plugs with extreme care, do not bump or drop them.

z

When installing, first tighten glow plugs by hand and then use the special
tool to tighten to the appropriate torque.

z

NEVER use a glow plug that has been dropped or hit, since it could be
fractured and can damage the engine!

z

Observe rules for cleanliness. See RULES FOR CLEANLINESS .

z

Verify that glow plug is correct and not damaged BEFORE starting the
engine whenever installing a glow plug, See GLOW PLUGS, CHECKING .

z

If the glow plug is broken, remove it and remove the broken fragment(s)
from the engine BEFORE starting the engine. Otherwise engine damage
can occur!

CAUTION: Part numbers are for reference only. Always check with your Parts Dept.

for the latest information.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Ignition Glow Plug System - New Beetle, 1.9L 4-Cyl. - BEW





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Ignition Glow Plug System - New Beetle, 1.9L 4-Cyl. - BEW
