Volkswagen New Beetle. Manual - part 1494





EVAP SYSTEM COMPONENTS, SERVICING

1. Leak Detection Pump (LDP) -V144-*/**

z

In right rear wheel housing, behind wheel housing liner

2. Connector

z

Black, 3-pin

3. Vacuum line

z

To intake manifold upper part. See Fig. 49 , item -6-.

NOTE:

z

Hose connections are secured with either spring-type or clamp-type clips.

z

Always replace clamp-type clips with spring-type clips.

z

Always replace clamp-type clips with spring-type clips. Assembly tool
VAS 5024 or hose clip pliers V.A.G 1921 are recommended for installing
spring-type clips.

Fig. 46: Identifying Special Tool
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

The following list refers to items in Fig. 47 .

z

Components marked with an * are checked by the self-diagnosis.

See Diagnostic tester VAS 5051; Vehicle self-diagnosis

z

Components marked with ** are checked by the final control diagnosis.

See Diagnostic tester VAS 5051; Vehicle self-diagnosis

NOTE:

The following list refers to items in Fig. 47 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

Press together at front to release

4. Breather pipe

z

Black

z

Check if seated securely

z

From changeover valve on fuel tank. See ENGINE CODES BEV, BGD , item -14-

z

Press together at front to release

5. To EVAP canister purge regulator valve -N80-

z

White

z

Check if seated securely

z

To EVAP canister purge regulator valve -N80-.

6. EVAP canister

z

In right rear wheel housing, behind wheel housing liner

z

To remove and install, remove turn signals

7. 10 N.m

8. 2 N.m

9. Air filter for leak detection pump

10. Connecting hose

z

Suction side

11. Connecting hose

z

Pressure side

Fig. 47: Exploded View Of EVAP System Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



EVAPORATIVE EMISSIONS (EVAP) SYSTEM, ASSEMBLY OVERVIEW

Engine codes AEG, AVH, AZG

z

Engine code BDC. See ENGINE CODE BDC

z

Engine codes BEV, BGD. See ENGINE CODES BEV, BGD

1. Tank flap unit

z

With rubber cup

2. Fuel tank

z

When removing, support with engine/transmission jack V.A.G 1383 A

z

Removing and installing. See FUEL TANK, REMOVING AND INSTALLING

3. Fuel delivery unit

z

Removing and installing. See FUEL DELIVERY UNIT, REMOVING AND INSTALLING

4. Throttle valve control module -J338-

5. Intake manifold upper part

6. Fuel rail with injectors

7. Fuel pressure regulator

8. Fuel filter

z

Installed position: Arrow points in direction of flow

9. EVAP canister purge regulator valve -N80-

z

On right in engine compartment above wheel housing liner

z

Installed position: Arrow points in direction of flow

z

Valve will be activated by engine control module (pulsed)

10. Test union

11. Gravity valve

12. Pressure retention valve

z

For fuel tank breather

z

Checking. See Checking Pressure Retention Valve

13. Change-over valve

z

Check. See Checking Change-Over Valve

14. EVAP canister

z

In right rear wheel housing, behind wheel housing liner

15. Leak Detection Pump (LDP) -V144-

z

At EVAP canister

z

Pump will be activated by engine control module (pulsed)

16. Air filter for LDP

NOTE:

The following list refers to items in Fig. 48 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 48: Hose Routing Diagram Of Evaporative Emissions (EVAP) System (Engine Codes AEG, AVH,
AZG)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine code BDC

1. Tank flap unit

2. Fuel tank

z

When removing, support with engine/transmission jack V.A.G 1383 A

z

Removing and installing. See FUEL TANK, REMOVING AND INSTALLING

3. Fuel delivery unit

z

Removing and installing. See FUEL DELIVERY UNIT, REMOVING AND INSTALLING

4. Intake hose

5. Throttle valve control module -J338-*

6. Intake manifold upper part

7. Fuel rail with injectors

8. Fuel pressure regulator

NOTE:

The following list refers to items in Fig. 49 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)
