Fig. 33: Unscrew Sealing Plug On Tamdem Pump z Connect pressure gauge VAS 5187 as shown in Fig. 34 . Fig. 34: Connecting VAS 5187 Pressure Gauge z Start engine and run at idling speed. z Connect vehicle diagnostic, test and information system VAS 5051 and select operating mode "vehicle z Select diagnostic function "08-Read measured value block". z Enter via number keys display group "2" and confirm with Q key. z Read idling speed in display zone 1. z Increase engine speed to above 1500 rpm. z Observe indicated pressure on gauge. Specification: at least 3.5 bar.
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW
|
