Fig. 22: Identifying Fuses (Behind Trim Panel On Far Left Side Of Dash) Checking function and voltage supply z Remove cover from fuel gauge sensor. z Switch ignition on. Fuel pump must be heard to run for approx. 2 seconds. z Switch ignition off. If fuel pump does not run: z Disconnect 4-pin connector from flange on fuel gauge sensor. z Connect diode test lamp V.A.G 1527 with adapter cables from V.A.G 1594 to outer contacts of Fig. 23: Connecting Diode Test Lamp With Adapter Cables To Outer Contacts Of Connector
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW
|
