Fig. 25: Connecting Remote Control V.A.G 1348/3A To Fuel Pump Fuse Contact
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Operate remote control.

If fuel pump runs:

z

Check activation of fuel pump relay referring to wiring diagram:

See appropriate SYSTEM WIRING DIAGRAM article.

If fuel pump does not run:

z

Remove 4-pin connector from flange (arrow).

Fig. 26: Removing 4-Pin Connector From Flange
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect diode test lamp V.A.G 1527 B with adapter cables from V.A.G 1594 A to outer contacts of



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



connector.

Fig. 27: Connecting Diode Test Lamp To Outer Contacts Of 4-Pin Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Operate remote control. LED must light up.

LED does not light up:

z

Locate and eliminate open circuit referring to current flow diagram:

See appropriate SYSTEM WIRING DIAGRAMS article.

LED lights up (voltage supply OK):

z

Remove union nut with spanner 3217.

Fig. 28: Removing Union Nut With Spanner
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

Check that electrical wires between flange and fuel pump are connected.

If no open circuit can be found:

z

Fuel pump faulty, replace fuel delivery unit. See FUEL DELIVERY UNIT, REMOVING AND
INSTALLING
 .

Checking delivery rate

Requirements

z

Voltage supply OK

z

Remote control V.A.G 1348/3A connected

Work sequence

z

Remove filler cap from fuel tank filler neck.

z

Pull off supply hose -3- (with white marking) (engine codes BEV, BGD: black markings) and collect fuel
that leaks out with a cloth.

Fig. 29: Removing Fuel Supply Hose
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect pressure gauge V.A.G 1318 with adapter V.A.G 1318/23 and V.A.G 1318/17 to fuel supply line.

WARNING:

The fuel system is under pressure! Before opening the system place
a cloth around the connection. Then release pressure by carefully
loosening the connection.

NOTE:

Press locking ring inward to release fuel line.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 30: Connect Pressure Gauge To Fuel Supply Line
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Push hose V.A.G 1318/16 onto adapter V.A.G 1318/11 on pressure gauge and hold hose in a measuring
container.

z

Open shut-off tap on pressure gauge. Lever then points in flow direction -A-.

z

Operate remote control V.A.G 1348/3A. Close cut-off tap slowly, until pressure gauge shows 3 bar
(except engine codes BEV and BGD). From now on do not alter setting of cut-off tap.

For engine codes BEV and BGD: 3.5 bar

z

Empty measuring container.

The quantity of fuel delivered by the fuel pump depends on the battery voltage. Therefore:

z

Connect multimeter to vehicle battery using adapter cables from V.A.G 1594 A.

z

Operate remote control for 30 seconds and measure battery voltage.

z

Compare quantity of fuel delivered with nominal value.

*) Minimum delivery cm

3

 /30 seconds



**) Voltage at fuel pump with engine at rest and pump running (approx. 2 volts less than battery
voltage).

NOTE:

The following list refers to items in Fig. 31 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)
