Volkswagen New Beetle. Manual - part 1449





adapt respective components to engine control module (see COMPONENTS AND FUNCTIONS,
ADAPTING
 ), and generate readiness code again.

FUEL GAUGE SENDER, REMOVING AND INSTALLING

Removing

z

Install fuel delivery unit. See FUEL DELIVERY UNIT, REMOVING AND INSTALLING .

z

Release and disconnect terminals for wires -3- and -4-.

z

Lift retaining tabs -1- and -2- with a screwdriver and pull fuel gauge sender out downward (arrows).

Fig. 15: Removing And Installing Fuel Gauge Sender
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Insert fuel gauge sender in guides on fuel delivery unit and push up until it engages.

z

Install fuel delivery unit. See FUEL DELIVERY UNIT, REMOVING AND INSTALLING .

FUEL TANK, REMOVING AND INSTALLING

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

V.A.G 1383 A Engine/transmission jack



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 16: Identifying V.A.G 1383 A Engine/Transmission Jack
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

V.A.G 1331 Torque wrench (5-50 N.m)

Fig. 17: Identifying V.A.G. 1331 Torque Wrench
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Check whether a coded radio is installed. If so, obtain anti-theft coding.

z

With ignition switched off disconnect battery Ground strap.

z

Open fuel flap.

z

Remove rear axle:

NOTE:

z

Observe safety precautions before starting work. See SAFETY
PRECAUTIONS WHEN WORKING ON THE FUEL SUPPLY SYSTEM .

z

Fuel extraction unit VAS 5190 is recommended to empty the fuel tank.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



See AXLE BEAM .

z

Remove right rear wheel housing liner:

See REAR WHEEL HOUSINGS LINER, ASSEMBLY OVERVIEW .

z

Remove cover for fuel tank (arrows).

Fig. 18: Removing Fuel Tank Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Drain fuel tank, clean fuel filler neck and surrounding area.

z

Disconnect breather lines/hoses on filler neck.

z

Remove mounting screw and remove tank flap unit with rubber cup.

See FUEL TANK FILLER FLAP UNIT, REMOVING AND INSTALLING .

z

Pull EVAP canister breather lines off.

z

Unhook gravity valve.

z

Remove securing bolt on filler neck.

z

Fold rear seat bench forward.

z

Remove cover from under fuel tank.

z

Remove cover from fuel delivery unit.

z

Remove 4-pin connector from flange (arrow).

WARNING:

Fuel supply lines are under pressure! Before removing a hose
connection wrap a cloth around the connection. Then release
pressure by carefully pulling the hose off the connection.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 19: Removing 4-Pin Connector From Flange
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect return hose -2- (blue), supply hose -1- (black) and breather hose -3- (white) at connecting
point.

Fig. 20: Disconnecting Return Hose, Supply Hose And Breather Hose
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Seal lines to avoid contamination of fuel system.

z

Remove tensioning strap. When doing this support fuel tank with engine/transmission jack V.A.G 1383
A.

WARNING:

Fuel supply lines are under pressure! Before removing a hose
connection wrap a cloth around the connection. Then release
pressure by carefully pulling the hose off the connection.

NOTE:

Press buttons on hose couplings to release.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)
