Volkswagen New Beetle. Manual - part 1452





Fig. 31: Fuel Pump Delivery Reference Graph
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Example: During the test, a voltage of 12.5 volts is measured on the battery. As the voltage at the pump is
approx. 2 volts less than the battery voltage, the result is a minimum delivery of 200 cm

3

 /30 s.

If the minimum delivery rate is not attained:

z

Check fuel lines for possible restrictions (kinks) or blockages.

z

Pull fuel line -1- off input side of fuel filter.

Fig. 32: Connecting Pressure Gauge With Adapter 1318/17 To Hose
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect pressure gauge V.A.G 1318 with adapter 1318/17 to hose.

z

Repeat delivery rate check.

NOTE:

Press locking ring inward to release fuel line.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



If the minimum delivery rate is now attained:

z

Replace fuel filter.

If the minimum delivery rate is again not attained:

z

Remove fuel delivery unit and check strainer for soiling.

Only if no faults have been detected up to now:

z

Fuel pump is faulty; replace fuel delivery unit. See FUEL DELIVERY UNIT, REMOVING AND
INSTALLING
 .

If the delivery rate has been attained but a fuel supply system fault (e.g. intermittent failure of fuel supply
system) is still suspected:

z

Check current draw of fuel pump as follows:

z

Reconnect all disconnected fuel lines.

z

Disconnect 4-pin connector from flange on fuel delivery unit.

z

Set multimeter to measuring range 20 A and make a series connection between connector contacts -1- and
fuel pump using adapter cables from V.A.G 1594 A.

Fig. 33: Connecting Multimeter In Series Between Connector Contacts And Fuel Pump
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Bridge contact -4- of connector and fuel pump using adapter cables from V.A.G 1594 A.

z

Start engine and run at idling speed.

z

Measure current draw of fuel pump.

NOTE:

The current clamp of multimeter V.A.G 1715 can be connected between
contacts -1- of connector and fuel pump, as an alternative solution.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Specification: max. 8 amps

If the current draw is exceeded:

z

Fuel pump is faulty; replace fuel delivery unit. See FUEL DELIVERY UNIT, REMOVING AND
INSTALLING
 .

Checking fuel pump non-return valve

Requirements

z

Remote control V.A.G 1348/3A is still connected

z

Pressure gauge V.A.G 1318 is still connected

Work sequence

z

Close pressure gauge cut-off tap (lever across flow direction, position -B-).

Fig. 34: Checking Fuel System Pressure Drop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Operate remote control at short intervals, until a pressure of approx. 3 bar has built up.

NOTE:

If the fuel system malfunction is intermittent, perform the check during a
road test with the help of a 2nd technician.

NOTE:

With this check the fuel supply line connections from the fuel delivery unit to
the point at which the pressure gauge V.A.G 1318 is connected will be checked
for leaks at the same time.

WARNING:

Danger of spray when opening the shut-off-tap; hold container in
front of the free connection on the pressure gauge.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

If pressure builds up too high, lower excess pressure by carefully opening shut-off tap.

z

Observe pressure drop on gauge.

Over a duration of 10 minutes pressure must not drop below 2.5 bar

If the pressure drops further:

z

Check line connections for leaks.

If no wiring fault is detected:

z

Fuel pump is faulty; replace fuel delivery unit. See FUEL DELIVERY UNIT, REMOVING AND
INSTALLING
 .

FUEL SYSTEM, BLEEDING

Engine codes BEV, BGD

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

V.A.G 1348/3 A Remote control

z

V.A.G 1348/3-2 Adapter cable

z

VAS 5226 Diesel suction pump

z

V.A.G 1318/20 Adapter

z

V.A.G 1318/20-1 Adapter

Fig. 35: Identifying Special Tools
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirements

z

Fuses must be OK



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)
