Volkswagen New Beetle. Manual - part 1444





Fig. 31: Identifying Special Tools And Equipment (VAS 5187 Pressure Gauge)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

V.A.G 1331 Torque wrench (5 to 50 N.m)

z

VAS 5051 Vehicle diagnostic, testing and information system with diagnostic cable VAS 5051/5A or
VAS 5051/6A

Fig. 32: Identifying Special Tools And Equipment (V.A.G 1331 Torque Wrench)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirements

z

Coolant temperature at least 85 C

z

Unit injectors OK

Work sequence

z

Unscrew sealing plug (arrow).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 33: Unscrew Sealing Plug On Tamdem Pump
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect pressure gauge VAS 5187 as shown in Fig. 34 .

Fig. 34: Connecting VAS 5187 Pressure Gauge
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Start engine and run at idling speed.

z

Connect vehicle diagnostic, test and information system VAS 5051 and select operating mode "vehicle
self-diagnosis". Enter control module engine electronics with address word "01".

z

Select diagnostic function "08-Read measured value block".

z

Enter via number keys display group "2" and confirm with Q key.

z

Read idling speed in display zone 1.

z

Increase engine speed to above 1500 rpm.

z

Observe indicated pressure on gauge.

Specification: at least 3.5 bar.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



z

Press <--key.

z

Press function 06-"End output".

z

Switch ignition off.

If specification is not obtained:

z

Replace tandem pump. See TANDEM PUMP, REMOVING AND INSTALLING .

TANDEM PUMP, REMOVING AND INSTALLING

Observe safety precautions, See SAFETY PRECAUTIONS WHEN WORKING ON THE FUEL SUPPLY
SYSTEM
 .

Observe rules for cleanliness, See RULES FOR CLEANLINESS .

Special tools and equipment

z

V.A.G 1331 Torque wrench (5 to 50 N.m)

z

V.A.G 1390 Vacuum pump

z

V.A.G 1390/1 Fluid receptacle

z

V.A.G 1921 Pliers for spring-type hose clips or VAS 5024 Assembly tool for spring-type clips

Fig. 35: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

NOTE:

Tighten the sealing plug to 25 N.m after having removed the pressure
gauge. Always replace the sealing ring.

WARNING:

z

The fuel and the fuel lines in the fuel system can become very hot



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



z

Pull supply hose -1- (white marking) and return hose -2- (blue marking) off fuel lines on cylinder head.

z

Attach hand vacuum pump V.A.G 1390 with bleed bottle V.A.G 1390/1 to return hose -3-.

Fig. 36: Attaching Hand Vacuum Pump V.A.G 1390 With Bleed Bottle V.A.G 1390/1 To Return
Hose

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Operate hand vacuum pump until no fuel is coming out of return hose. Observe that no fuel is siphoned
into hand vacuum pump.

z

Remove vacuum hose -1 - from brake booster of tandem pump -4-.

z

Remove supply hose -2- (white marking) from tandem pump -4-.

z

Remove securing bolts (arrow).

z

Remove tandem pump -4- from cylinder head.

z

Pull tandem pump -4- upward slightly, pull return hose -3- off (blue marking) and remove tandem pump -
4-.

(danger of scalding)!

z

The fuel system is also under pressure! Before opening the system,
place cloths around the connections. Then carefully loosen the
connection to release pressure.

z

Wear eye and hand protection when performing any type of repair
work on the fuel system!



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW
