Volkswagen New Beetle. Manual - part 1442





Fig. 20: Identifying Special Tools And Equipment (V.A.G 1527 B Diode Test Lamp)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

V.A.G 1715 Multimeter

z

Wiring diagram

Fig. 21: Identifying Special Tools And Equipment (V.A.G 1715 Multimeter)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirements

z

Battery charge at least 11.5V

z

Fuses OK

z

All electrical consumers, e.g. lights and rear window defogger are switched off



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 22: Identifying Fuses (Behind Trim Panel On Far Left Side Of Dash)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking function and voltage supply

z

Remove cover from fuel gauge sensor.

z

Switch ignition on. Fuel pump must be heard to run for approx. 2 seconds.

z

Switch ignition off.

If fuel pump does not run:

z

Disconnect 4-pin connector from flange on fuel gauge sensor.

z

Connect diode test lamp V.A.G 1527 with adapter cables from V.A.G 1594 to outer contacts of
connector.

Fig. 23: Connecting Diode Test Lamp With Adapter Cables To Outer Contacts Of Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



z

Switch ignition on.

LED must light up for approx. 2 seconds.

LED does not light up:

z

Check activation of fuel pump relay and check wiring for open and short circuit.

See appropriate System Wiring Diagrams article.

LED lights up (voltage supply OK.):

z

Remove fuel gauge sensor, See FUEL DELIVERY UNIT, REMOVING AND INSTALLING .

z

Check that electrical wires between flange and fuel pump are connected and for continuity.

If no open circuit can be found:

z

Fuel pump faulty, replace fuel gauge sensor, See FUEL DELIVERY UNIT, REMOVING AND
INSTALLING
 .

Checking current draw of fuel pump

z

Disconnect 4-pin connector on fuel gauge sensor.

z

Set multimeter to measuring range 20 A and make a series connection between connector contacts -1- and
fuel pump using adapter cables from V.A.G 1594 A.

Fig. 24: Checking Current Draw Of Fuel Pump
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

The current clamp of multimeter V.A.G 1715 can be connected between
contacts -1- of connector and fuel pump, as an alternative solution.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



z

Bridge contact -4- of connector and fuel pump using adapter cables from V.A.G 1594 A.

z

Start engine and run at idling speed.

z

Measure current draw of fuel pump. Specification: 3.5 to 4.5 Amps

If the measured value is out of specification:

z

Replace fuel gauge sensor, See FUEL DELIVERY UNIT, REMOVING AND INSTALLING .

DELIVERY PRESSURE AND DELIVERY RATE OF FUEL PUMP, CHECKING

Special tools and equipment

z

3217 Ring nut wrench

z

V.A.G 1318 Pressure gauge

z

V.A.G 1318/1 Adapter

z

V.A.G 1318/11 Adapter

z

V.A.G 1318/17 Adapter

z

V.A.G 1318/23 Adapter

Fig. 25: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

If irregularities occur when driving at high speed and:

z

no faults are stored in the control module DTC memory (see ENGINE
CONTROL MODULE (DTC) MEMORY, READING AND ERASING ).

z

tandem pump is OK (See TANDEM PUMP, CHECKING )

z

and fuel filter change intervals are kept,

the delivery pressure and delivery rate of fuel pump must be checked.
