Special tools and equipment

z

V.A.G 1331 Torque wrench (5 to 50 N.m)

Fig. 15: Identifying Special Tools And Equipment (V.A.G 1331 Torque Wrench)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

V.A.G 1383 A Engine/transmission jack

Fig. 16: Identifying Special Tools And Equipment (V.A.G 1383 A Engine/Transmission Jack)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Open fuel flap.

z

Check whether a coded radio is installed. If so, obtain anti-theft coding.

z

With ignition switched off disconnect battery Ground (GND) strap.

z

Remove tank flap unit with rubber cup.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



See FUEL TANK FILLER FLAP UNIT, REMOVING AND INSTALLING .

z

Fold rear bench seat forward.

z

Remove cover from fuel gauge sensor and separate connection.

z

Remove rear axle:

See AXLE BEAM .

z

Remove rear right wheelhouse liner:

See REAR WHEEL HOUSINGS LINER, ASSEMBLY OVERVIEW .

z

Unscrew protective cover -1- (arrows).

Fig. 17: Unscrew Protective Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove cover for fuel tank (arrows).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 18: Removing Fuel Tank Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Drain fuel tank and clean area of fuel filler neck (unscrew filler cap).

z

Disconnect breather lines/hoses on filler neck.

z

Remove gravity valve from its retainer.

z

Remove mounting screws on filler neck.

z

Disconnect supply and return lines on right front of fuel tank.

WARNING:

z

The fuel and the fuel lines in the fuel system can become very
hot (danger of scalding)!

z

The fuel system is also under pressure! Before opening the
system, place cloths around the connections. Then carefully
loosen the connection to release pressure.

z

Wear eye and hand protection when performing any type of
repair work on the fuel system!

NOTE:

Press locking ring inward to release fuel lines (arrows).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 19: Disconnecting Supply And Return Lines On Right Front Of Fuel Tank
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Seal lines so that fuel system is not contaminated by dirt etc.

z

Remove tensioning strap. When doing this support fuel tank with engine/transmission jack V.A.G 1383
A.

z

Lower fuel tank. Guide vent hoses/lines through longitudinal member.

Installing

Installation is performed in the reverse order. Note the following:

z

Route breather and fuel lines free of kinks.

z

Make sure fuel lines/hoses are installed securely.

z

Guide vent hoses/lines through opening in longitudinal member (install line guide).

z

Secure breather hoses/lines to filler neck with spring-type clamps.

z

Do not interchange supply and return hose (return hose blue, supply hose black).

z

Clip supply and return line onto fuel tank.

FUEL PUMP, CHECKING ELECTRICALLY

Special tools and equipment

z

V.A.G 1527 B Diode test lamp
