Volkswagen New Beetle. Manual - part 1445





Fig. 37: Removing Tandem Pump Securing Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Installation is performed in reverse order. Note the following:

z

Observe correct seat of tandem pump coupling in the camshaft.

z

Always replace tandem pump seals.

z

Connect return hose -3- (blue marking) to tandem pump return connection.

z

Install tandem pump and tighten upper securing bolts to 20 N.m.

z

Tighten lower securing bolts to 10 N.m.

z

Connect supply hose -2- (white marking) to supply connection and vacuum line -1- of brake booster to
tandem pump -4-.

Fig. 38: Tightening Tandem Pump Lower Securing Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



z

Connect supply hose -1- (white marking) to fuel line of cylinder head.

z

Attach hand vacuum pump V.A.G 1390 with bleed bottle V.A.G 1390/1 to return hose -3-. See Fig. 39 .

z

Operate hand vacuum pump until no fuel is coming out of return hose -3-. Observe that no fuel is
siphoned into hand vacuum pump.

z

Connect return hose -2- (blue marking) to return hose -3-.

Fig. 39: Attaching Hand Vacuum Pump V.A.G 1390 With Bleed Bottle V.A.G 1390/1 To Return
Hose

Courtesy of VOLKSWAGEN OF AMERICA, INC.

ACCELERATOR MECHANISM, SERVICING

1. Mounting

2. Connector

z

Black, 6-pin

3. 10 N.m

4. Throttle Position (TP) Sensor -G79-

z

Can not be adjusted

z

Sensor passes position of pedal on to engine control module

z

Remove footwell cover to remove sensor

5. Bracket

z

For footwell cover

z

Clipped securely onto accelerator pedal (TP) position sensor

NOTE:

The following list refers to items in Fig. 40 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 40: Identifying Accelerator Mechanism Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



1998-2004 ENGINE

Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)

FUEL SUPPLY SYSTEM, SERVICING

FUEL SUPPLY SYSTEM, GENERAL INFORMATION

NOTE:

z

Hose connections are secured with either spring-type or clamp-type clips.

z

Always replace clamp-type clips with spring-type clips.

z

Fuel hoses of engine must only be secured with spring type clips. The use
of clamp or screw-type clips is not permitted.

z

Fuel extraction unit VAS 5190 is recommended to empty fuel tank.

Fig. 1: Identifying Special Tool (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Always replace clamp-type clips with spring-type clips. Assembly tool
VAS 5024 or hose clip pliers V.A.G 1921 are recommended for installing
spring-type clips.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)
