Volkswagen New Beetle. Manual - part 1398







2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 133: Scan Tool Display - Replacing Engine Control Module (1 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Press Scan Tool print button to print out ECM identification.

z

Press --> button.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 134: Scan Tool Display - Replacing Engine Control Module (2 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Press -0- and -6- buttons to select Function 06: "End output"

z

Press -Q- button to enter input.

Display will appear as shown:

Fig. 135: Scan Tool Display - Replacing Engine Control Module (3 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
