Volkswagen New Beetle. Manual - part 1397





If specification obtained:

z

Switch Fluke 83 multimeter to 20 Volt range.

z

Connect multimeter between terminals 1 and 2 of ECM connector using jumper wires from VW 1594
Adapter kit.

Fig. 130: Identifying Change-Over Valve For Intake Manifold Flap -N239- Harness Connector
Terminals

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Start engine and let idle.

z

Specification: between 5 and 6 Volts

z

Switch OFF ignition.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Voltage value must rise to 11 to 15 Volts (battery Voltage) and after approx. 3 seconds fall to 0 Volts.

If Voltage values do not change as described:

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.

Fig. 131: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring for open circuit between Test Box and connector using Wiring diagram.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 132: Identifying Change-Over Valve For Intake Manifold Flap -N239- Harness Connector
Terminals

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Up to MY 1999

z

Terminal 1 + socket 3

z

Terminal 2 + sockets 2 and 28

From MY 2000

z

Terminal 1 + socket 81

z

Terminal 2 + sockets 1 and 2

z

Wire resistance: 1.5 ohm maximum



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Check wires for shorting to: one another, Ground and Battery +.

z

Specification: INFINITY ohm

If wiring OK:

z

Replace Engine Control Module -J248-. See Engine Control Module (ECM), replacing .

DIESEL DIRECT FUEL INJECTION (DFI) ENGINE CONTROL MODULE (ECM) -J248-,
REPLACING AND CODING

Engine Control Module (ECM), replacing

Special tools

z

VAG1551/1552 Scan Tool using VAG1551/3 Adapter cable

Work sequence

z

Print out the ECM identification (and thereby the previous ECM coding) as follows:

z

Connect VAG1551/1552 Scan Tool. See VAG1551/1552 SCAN TOOL, CONNECTING .

z

Press -0- and -1- buttons to select Address word 01: "Engine electronics"

Display will appear as shown (I.D. example only):



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
