z

Terminal 4 + socket 30

z

Terminal 5 + socket 68

z

Wire resistance: 1.5 ohm maximum

z

Check wires for short to one another, to Ground and to Battery +

z

Specification: INFINITY ohm

If wiring OK:

z

Replace Engine Control Module -J248-. See Engine Control Module (ECM), replacing .

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:

z

Set the readiness code. See READINESS CODE, SETTING .

Change-over valve for intake manifold flap -N239-, checking

Special tools

z

VAG1390 Hand vacuum pump



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 128: Identifying Special Tool VAG 1390 Hand Vacuum Pump
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAG1598/22 Test Box (MY 1999)

z

VAG1598/31 Test Box (from MY 2000)

z

Fluke 83 multimeter

z

VW 1594 Adapter kit

z

Wiring diagram

Function, checking

z

Start engine and let idle.

z

Switch OFF ignition.

z

Observe position of lever on intake manifold change-over flap (using 2nd technician)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Intake manifold change-over flap must (after switching OFF ignition) close back and after approx. 3
seconds re-open.

If change-over does not occur, perform following checks:

z

Check intake manifold change-over flap mechanics for freedom of movement by manually operating the
rods by hand.

z

Check vacuum function of positioning actuator using VAG1390 hand vacuum pump.

z

Check vacuum lines for correct connection.

If mechanical components OK:

z

Check Intake Manifold Change-over Valve - N239-.

Test sequence

z

Disconnect -N239- harness connector.

z

Measure resistance between -N239- terminals.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 129: Measuring Resistance Between Change-Over Valve For Intake Manifold Flap -N239-
Terminals

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Specification: 25 to 45 ohm

If specification not obtained:

z

Replace Intake Manifold Change-over Valve -N239-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
