Fig. 44: Scan Tool Display - Engine Coolant Temperature Sensor (3 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

{

Press -0-, -0- and -7- buttons to select "Display group 7".

{

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 45: Scan Tool Display - Engine Coolant Temperature Sensor (4 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

{

Observe Engine Coolant Temperature value in Display zone 4.

z

Temperature value must Increase uniformly without interruption.

If an unrealistic value appears in Display zone 4 or Fuel temperature is displayed as a substitute

{

Check Engine Coolant Temperature (ECT) Sensor -G62- and wiring to sensor as follows

{

Press --> button.

Display will appear as shown:

NOTE:

In the event of malfunctions, Fuel temperature is displayed as a substitute.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 46: Scan Tool Display - Engine Coolant Temperature Sensor (5 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

{

Press -0- and -6- buttons to select Function 06: "End output".



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



{

Press -Q- button to enter input.

{

Switch OFF ignition.

{

Disconnect -G62- harness connector (arrow).

Fig. 47: Disconnecting ECT Sensor -G62- Harness Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Measure resistance between sensor terminals 1 + 3.
