Volkswagen New Beetle. Manual - part 1374





Fig. 38: Scan Tool Display - MAP Sensor & BARO Sensor (4 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Specification: pressures must be the same (+/-30 mbar)

If value in Display zone 2 deviates:

z

Replace Engine Control Module -J248-. See Engine Control Module (ECM), replacing .

If value in Display zone 3 deviates:

z

Press --> button.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 39: Scan Tool Display - MAP Sensor & BARO Sensor (5 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Press -0- and -6- buttons to select Function 06: "End output".

z

Press -Q- button to enter input.

z

Switch OFF ignition.

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 40: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect -G71- harness connector. See DIESEL INJECTION SYSTEM, COMPONENT
LOCATIONS OVERVIEW
 .

z

Check wiring for open circuit between Test Box and connector using Wiring diagram.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
