Volkswagen New Beetle. Manual - part 1372





z

Connect fuel injector to fuel injector test stand.

Fig. 29: Connecting Fuel Injector To Fuel Injector Test Stand
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Move pump lever down slowly. When spray begins, record opening pressure for deviations from
specification replace injector.

z

Specification (new injectors): 220 - 230 bar

z

Wear limit: 200 bar

Fuel injectors, leak-checking

z

Pressure gauge on

z

Move pump lever down slowly and maintain a pressure of approx. 150 bar for 10 seconds.

z

No fuel should leak from the nozzle tip.

z

If any injector(s) leak, replace.

Diesel injection pump timing cover O-ring, replacing

z

Place a clean cloth under the Diesel injection pump.

z

Remove cover screws -1- with commercially available tool for Torx socket head screws, e.g. Hazet 2115
-T30.

z

Remove cover -2- and clean thoroughly.

z

Replace O-ring -3- and install cover using existing shims -4-.

which could result in severe injuries.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 30: Removing Injection Pump Timing Cover Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

DIESEL FUEL INJECTION COMPONENTS AND FUNCTIONS, CHECKING

Diesel injection system Voltage supply, checking

Special tools

z

VAG1598/22 Test Box (MY 1999)

WARNING:

Make sure that no electronic components are destroyed during testing by
observing the following:

z

Switch the Fluke 83 multimeter to the appropriate units range before
connecting measuring cables!

z

Always observe checking requirements!

NOTE:

z

Use the Fluke 83 multimeter and VAG1527B Voltage tester for electrical
checking.

z

Specifications are valid for an ambient temperature range from: 0 to + 40 °
C (+32 to 104 °F).

z

If measured values deviate only slightly from the specifications, clean the
sockets and plugs on the tester and measuring cables, then repeat check.
Before replacing a component, check wiring and connections. In cases of
specifications less than 10 ohm repeat the resistance measurement on the
component.

z

To connect a tester to the Test Box, use jumper wires from the VW 1594
adapter kit.

z

The terminal numbers of the plugs and the socket numbers on the Test
Box are identical.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

VAG1598/31 Test Box (from MY 2000)

z

Fluke 83 multimeter

z

VW 1594 Adapter kit

z

Wiring diagram

Test requirements

z

Battery Voltage OK.

Test sequence

z

Switch OFF ignition.

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.

Fig. 31: Connecting VAG1598/22 Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Bridge sockets with jumper wires from VW 1594 kit.

z

Up to MY 1999: sockets 33 + 1

z

From 2000: sockets 18 + 4

z

Measure Voltage between following sockets:

z

Up to MY 1999: sockets 2 + 1, 28 + 1, 27 + 2 and 28 + 27

z

From 2000: sockets 1 + 4, 2 + 4, 1 + 5, 2 + 5

z

Specification: approx. battery Voltage

If specification not obtained:

z

Check power supply relay -J31-, terminal 30.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

-J317- located on fuse relay panel above the central electric.

z

Check wiring for open circuit, short circuit and transfer resistance at terminals using Wiring diagram.

If wiring and relay OK:

z

Replace Engine Control Module -J248-. See Engine Control Module (ECM), replacing .

Engine speed (RPM) sensor -G28-, checking

Engine speed (RPM) sensor -G28- serves dual purpose of speed and reference mark sensor. An inoperative
sensor will stop engine.

Special tools

z

VAG1598/22 Test Box (MY 1999)

z

VAG1598/31 Test Box (from MY 2000)

z

Fluke 83 multimeter

z

VW 1594 Adapter kit

z

Wiring diagram

Test sequence

z

Switch OFF ignition.

z

Disconnect -G28- harness connector. See DIESEL INJECTION SYSTEM, COMPONENT
LOCATIONS OVERVIEW
 .

z

Measure resistance between connector terminals 1 + 2.

z

Specification: 1000 to 1500 ohm

Fig. 32: Identifying Engine RPM Sensor Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
