Volkswagen New Beetle. Manual - part 1377





Fig. 48: Identifying Resistance Between ECT Sensor Terminals 1 And 3
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Specification (see diagram):

Scale A shows resistance values for temperature range 0 to 50 °C and scale B the values for temperature range
50 to 100 °C.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 49: ECT Sensor Resistance Versus Temperature Range Graph
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Examples:

z

30 °C corresponds to a resistance from 1500 to 2000 ohm

z

80 °C corresponds to a resistance from 275 to 375 ohm

If specification not obtained:

z

Replace Engine Coolant Temperature (ECT) Sensor -G62-.

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:

z

Set the readiness code. See READINESS CODE, SETTING .

If specification obtained:

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 50: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring for open circuit between Test Box and 4-pin harness connector using Wiring diagram.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 51: Identifying ECT Sensor Harness Connector Terminals 1 And 3
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Up to MY 1999

z

Terminal 1 + socket 70

z

Terminal 3 + socket 54

From MY 2000

z

Terminal 3 + socket 112

z

Terminal 4 + socket 104

z

Wire resistance: 1.5ohm maximum

z

Check wires for shorting to: one another, Ground and Battery +



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
