Volkswagen New Beetle. Manual - part 1350





z

Press -Q- button to confirm input

z

Switch ignition off.

ADDITIONAL SIGNALS, CHECKING

Vehicle Speed signal, checking

The speed signal is required for A/C compressor cut-off when accelerating, for the Cruise Control System and
to improve driveability smoothness (jolt damping).

Special tools

z

VAG1551/1552 Scan Tool using VAG1551/3 Adapter cable

z

VAG1598/22 Test Box (MY 1999)

z

VAG1598/31 Test Box (from MY 2000)

z

VW 1594 Adapter kit

z

VAG1527B Voltage tester

z

Wiring diagram

Checking requirements

z

Speedometer function and speedometer display OK.

Test sequence

z

Connect VAG1551/1552 Scan Tool. See VAG1551/1552 SCAN TOOL, CONNECTING .

z

Start engine and let idle.

z

Press -0- and -1- buttons to select Address word 01: "Engine electronics"

Display will appear as shown (example only):

WARNING:

Secure Scan Tool to rear seat and operate from this position using a
second technician.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 156: Scan Tool Display - Vehicle Speed Signal (1 Of 4)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press --> button.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 157: Scan Tool Display - Vehicle Speed Signal (2 Of 4)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Press -0- and -8- buttons to select Function 08: "Read measuring value block".

z

Press -Q- button to enter input.

Display will appear as shown:

Fig. 158: Scan Tool Display - Vehicle Speed Signal (3 Of 4)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -0-, -0- and -6- buttons to select "Display group 6".

z

Press -Q- button to enter input.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
