Volkswagen New Beetle. Manual - part 1349





Fig. 152: Scan Tool Display - Activating & Deactivating Cruise Control System (3 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press buttons -0- and -6- buttons to select "End output" function 06

z

Press -Q- button to confirm input

z

Switch ignition off and then on again.

z

Switch ignition off.

Checking CCS activation/deactivation

z

Connect VAG1551/1552 Scan Tool. See VAG1551/1552 SCAN TOOL, CONNECTING .

z

Press buttons -0- and -1- to insert "Engine electronics" address word 01.

Indicated on display:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 153: Scan Tool Display - Checking CCS Activation/Deactivation (1 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press buttons -0- and -8- to select Function 08 "Read measuring value block" function 08.

z

Press -Q- button to confirm input

Indicated on display:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 154: Scan Tool Display - Checking CCS Activation/Deactivation (2 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press buttons -0-, -0- and -6- to input display group number 006 and press -Q- button to confirm input.

z

Check the specified value in display field 2:

Cruise Control Code Chart - Display Field 4

z

Press --> button

Indicated on display:

Value

Display field 4

0 or 1

cruise control system activated

255

cruise control system deactivated



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 155: Scan Tool Display - Checking CCS Activation/Deactivation (3 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press buttons -0- and -6- buttons to select "End output" function 06



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
