Volkswagen New Beetle. Manual - part 1348





Fig. 148: Scan Tool Display - Checking Cruise Control System (Automatic Transmission) (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Press -0- and -6- buttons to select Function 06: "End output".

z

Press -Q- button to enter input.

z

Switch OFF ignition.

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.

Fig. 149: Connecting VAG 1598/22 Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring for open/short circuits between the Engine Control Module and the Cruise Control System
switches using Wiring diagram.

See appropriate System Wiring Diagram article.

Cruise Control System, activating and deactivating



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Connect VAG1551/1552 Scan Tool. See VAG1551/1552 SCAN TOOL, CONNECTING .

z

Press buttons -0- and -1- to insert "Engine electronics" address word 01.

Indicated on display:

Fig. 150: Scan Tool Display - Activating & Deactivating Cruise Control System (1 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press buttons -1- and -1- to select "Login procedure" function 11.

z

Press -Q- button to confirm input

Indicated on display:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 151: Scan Tool Display - Activating & Deactivating Cruise Control System (2 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Enter relevant code number:

Cruise Control Code Chart

z

Press -Q- button to confirm input

Indicated on display:

Code
11463

activate cruise control system

16167

deactivate cruise control system



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
