Volkswagen New Beetle. Manual - part 1346





Fig. 141: Scan Tool Display - Checking Cruise Control System (1 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press --> button.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 142: Scan Tool Display - Checking Cruise Control System (2 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -0- and -8- buttons to select Function 08: "Read measuring value block".

z

Press -Q- button to enter input.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 143: Scan Tool Display - Checking Cruise Control System (3 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Press buttons -0-, -0- and -6- to select "Display group 6".

z

Press -Q- button to enter input.

z

Observe display in Display zone 4.

Specification: 0

Fig. 144: Scan Tool Display - Checking Cruise Control System (4 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

If 255 is displayed in zone 4:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
