z

Insert new ECM and press to the left.

z

Tighten nut for ground wire (located in front of ECM) to 9 +/- 1 Nm (80 +/- 9 in. lb)

z

Check previous ECM coding and coding of new ECM. See ENGINE CONTROL MODULE (ECM),
CODING
 .

z

Activate Cruise Control System. See CRUISE CONTROL SYSTEM, ACTIVATING AND
DEACTIVATING
 .

z

Check DTC memory of new ECM, erase if necessary. See DTC MEMORY, CHECKING .

z

Adapt new control module to immobilizer. See ANTI-THEFT IMMOBILIZER, ON BOARD
DIAGNOSTIC (OBD)
 .

Engine Control Module (ECM), coding

If appropriate code for vehicle is not displayed or if ECM has been replaced, code ECM as follows.

Special tools

z

VAG1551/1552 Scan Tool using VAG1551/3 Adapter cable

Work sequence

z

Connect VAG1551/1552 Scan Tool. See VAG1551/1552 SCAN TOOL, CONNECTING .

z

Switch ON ignition but do not start engine.

z

Press -0- and -1- buttons to select Address word 01: "Engine electronics"

Display will appear as shown (I.D. example only):



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 137: Scan Tool Display - Coding Engine Control Module (1 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press --> button.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 138: Scan Tool Display - Coding Engine Control Module (2 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Press -0- and -7- buttons to select Function 07: "Code control module".

z

Press -Q- button to enter input.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
