Volkswagen New Beetle. Manual - part 1342





Fig. 132: Identifying Change-Over Valve For Intake Manifold Flap -N239- Harness Connector
Terminals

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Up to MY 1999

z

Terminal 1 + socket 3

z

Terminal 2 + sockets 2 and 28

From MY 2000

z

Terminal 1 + socket 81

z

Terminal 2 + sockets 1 and 2

z

Wire resistance: 1.5 ohm maximum



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Check wires for shorting to: one another, Ground and Battery +.

z

Specification: INFINITY ohm

If wiring OK:

z

Replace Engine Control Module -J248-. See Engine Control Module (ECM), replacing .

DIESEL DIRECT FUEL INJECTION (DFI) ENGINE CONTROL MODULE (ECM) -J248-,
REPLACING AND CODING

Engine Control Module (ECM), replacing

Special tools

z

VAG1551/1552 Scan Tool using VAG1551/3 Adapter cable

Work sequence

z

Print out the ECM identification (and thereby the previous ECM coding) as follows:

z

Connect VAG1551/1552 Scan Tool. See VAG1551/1552 SCAN TOOL, CONNECTING .

z

Press -0- and -1- buttons to select Address word 01: "Engine electronics"

Display will appear as shown (I.D. example only):



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 133: Scan Tool Display - Replacing Engine Control Module (1 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Press Scan Tool print button to print out ECM identification.

z

Press --> button.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
