Volkswagen New Beetle. Manual - part 1340





Fig. 126: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring for open circuit between Test Box and connections using Wiring diagram.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 127: Identifying MAF Sensor -G70- Harness Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Up to MY 1999

z

Terminal 2 + socket 2 and 28

z

Terminal 3 + socket 4

z

Terminal 4 + socket 50

z

Terminal 5 + socket 52

From MY 2000

z

Terminal 2 + socket 1 and 2

z

Terminal 3 + socket 49



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Terminal 4 + socket 30

z

Terminal 5 + socket 68

z

Wire resistance: 1.5 ohm maximum

z

Check wires for short to one another, to Ground and to Battery +

z

Specification: INFINITY ohm

If wiring OK:

z

Replace Engine Control Module -J248-. See Engine Control Module (ECM), replacing .

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:

z

Set the readiness code. See READINESS CODE, SETTING .

Change-over valve for intake manifold flap -N239-, checking

Special tools

z

VAG1390 Hand vacuum pump



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 128: Identifying Special Tool VAG 1390 Hand Vacuum Pump
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAG1598/22 Test Box (MY 1999)

z

VAG1598/31 Test Box (from MY 2000)

z

Fluke 83 multimeter

z

VW 1594 Adapter kit

z

Wiring diagram

Function, checking

z

Start engine and let idle.

z

Switch OFF ignition.

z

Observe position of lever on intake manifold change-over flap (using 2nd technician)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
