Fig. 72: Identifying IAT Sensor -G72- Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Measure resistance between sensor terminals 1 + 2.

Specification (see Fig. 73 ):

Scale A shows resistance values for temperature range 0 to 50 °C and scale B the values for temperature range
50 to 100 °C.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 73: IAT Sensor Resistance Versus Temperature Range Graph
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Examples:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

30 °C corresponds to a resistance from 1500 to 2000ohm

z

80 °C corresponds to a resistance from 275 to 375ohm

If specification not obtained:

z

Replace Intake Air Temperature (IAT) Sensor -G72-.

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:

z

Set the readiness code. See READINESS CODE, SETTING .

If specification obtained:

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 74: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring between Test Box and connector for open circuit using Wiring diagram.
